约翰迪尔零件查询300B - BACKHOE, LOADER HEAVY-DUTY BACKHOE BUCKETS (9250 BACKHOE) [02F20]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 991 次

Pos.	Part No	Qty	Parts name	Comments
1.	U42740	[1]	Cutting Edge	SIDE, R.H.
2.	U42753	[1]	Cutting Edge	FRONT FOR 457 MM (18") BUCKET
2.	U42752	[1]	Cutting Edge	FRONT FOR 610 MM (24") BUCKET
3.	T40910	[3]	Pin	(SUB FOR U13927)
4.	U43792	[3]	Bucket Tooth Adapter	(SUB FOR (3) U42750)
5.	U42751	[3]	Point
6.	U42741	[1]	Cutting Edge	SIDE, L.H.
7.	........	[1]	Backhoe Bucket	457 MM (18") ( AT37733 NO LONGER AVAILABLE, ORDER INDIVIDUAL PARTS)
7.	........	[1]	Backhoe Bucket	610 MM (24") (USE AT37734 IF AVAILABLE) (SUB AT114252)
8.	........	[1]	Plate	PIVOT L.H. (INCLUDES BUSHINGS) (SUB AT36087)
9.	U42738	[2]	Bushing
10.	U42737	[4]	Bushing
11.	28H2239	[1]	Spacer	BUCKET LINKAGE, 1-1/4" X 7"
12.	U11651	[2]	Washer
13.	11H221	[4]	Cotter Pin	3/8" X 2-1/2"
14A.	T59459	[1]	Pin Fastener	COUPLER LINKS TO BUCKET, (SUB AU42426)
14B.	AU42426	[1]	Pin Fastener	COUPLER LINKS TO BUCKET
15.	........	[1]	Plate	PIVOT R.H. (INCLUDES BUSHINGS) (SUB AT36087)
16.	U11649	[2]	Washer
17A.	T59451	[1]	Pin Fastener	(SUB AU42334)
17B.	AU42334	[1]	Pin Fastener
18.	........	[AR]	Tooth	(3 USED WITH 457 MM (18") BUCKET, 4 USED WITH 610 MM (24") BUCKET) ( AU41838 - NO LONGER AVAILABLE) (SUB T40910, U43792 AND U42751)
19.	AT36087	[1]	Plate
20.	T59447	[2]	Snap Ring
21.	T59452	[2]	Snap Ring
