约翰迪尔零件查询300B - BACKHOE, LOADER SWING CYLINDER (SERIAL NO. 039797- ) [02H09]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 245 次

Pos.	Part No	Qty	Parts name	Comments
1.	T48260	[1]	Hydraulic Cylinder Cap
2.	R78993	[2]	Back-Up Ring	(B) (SUB FOR U10777, THIS APPLICATION)
3.	U10776	[2]	O-Ring	(B)
4.	22H1077	[2]	Set Screw	1/4" X 5/16"
5.	U43454	[2]	Bushing
6.	AT46827	[1]	Hydraulic Cylinder Barrel
7.	JD7759	[2]	Lubrication Fitting	STRAIGHT, 1/8"
8.	C17964	[1]	Ring
9.	T46628	[1]	Shaft Key
10.	T45737	[1]	Ring
11.	T60873	[1]	Piston
12.	U17217	[1]	Wear Ring	(B)
13.	R31378	[1]	O-Ring	(B)
14.	R79117	[2]	Back-Up Ring	(B) (SUB FOR T50240, THIS APPLICATION)
15.	T60874	[1]	Seal	(B)
16.	R76775	[1]	Seal	(B) (SUB FOR T50241)
17.	U41823	[1]	Wear Ring	(B)
18.	R80920	[1]	Guide	(SUB FOR T48264)
19.	U46283	[1]	Seal	(B)
20.	T33708	[1]	Bushing
21.	AT46829	[1]	Hydraulic Cylinder Rod
22.	JD7797	[1]	Lubrication Fitting	STRAIGHT, 1/4"
23.	T60875	[1]	Washer	(B)
24.	AR105300	[2]	Hydraulic Cylinder	SWING, (SUB FOR AT58338)
...	RE18756	[1]	Hydraulic Cylinder Kit	REPAIR CYLINDER, (SUB FOR AT58361 AND AR105283)
