约翰迪尔零件查询300D - BACKHOE, LOADER Service Brake HydraulicsEPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 968 次

Pos.	Part No	Qty	Parts name	Comments
1.	28H3381	[1]	Spacer	0.493" X 0.675" X 5/8"
2.	28H1495	[1]	Spacer	0.493" X 0.675" X 1"
3.	T29969	[1]	Clamp
4.	19H3217	[1]	Cap Screw	3/8" X 1-3/4"
5.	14H1076	[1]	Nut	3/8"
6.	24M7239	[1]	Washer	10.700 X 21 X 2.500 MM
7.	T47700	[1]	Angle
8.	24M7239	[AR]	Washer	10.700 X 21 X 2.500 MM
9.	24H1781	[AR]	Washer	13/32" X 7/8" X 1/4"
10.	T29969	[1]	Clamp
10.	T29969	[1]	Clamp
11.	19H3239	[1]	Cap Screw	3/8" X 1-1/4"
12.	14H1076	[1]	Nut	3/8"
12.	14H1076	[1]	Nut	3/8"
13.	T29969	[1]	Clamp
13.	T29969	[1]	Clamp
14.	24M7239	[AR]	Washer	10.700 X 21 X 2.500 MM
14.	24M7239	[1]	Washer	10.700 X 21 X 2.500 MM
15.	T47700	[1]	Angle
15.	T47700	[1]	Angle
16.	24M7239	[1]	Washer	10.700 X 21 X 2.500 MM
16.	24M7239	[1]	Washer	10.700 X 21 X 2.500 MM
17.	19H2284	[1]	Cap Screw	3/8" X 7/8" (SUB FOR 19H1648, THIS APPLICATION)
18.	........	[1]	Kit	RIGHT ( AT172102 NLA) (SUB FOR AT150479)
18.	........	[1]	Kit	LEFT ( AT172103 NLA) (SUB FOR AT149701)
19.	AT145272	[1]	Hydraulic Hose - Fabricate
20.	AT167890	[1]	Hydraulic Hose - Fabricate
20.	AT167890	[1]	Hydraulic Hose - Fabricate
21.	TY22462	[2]	Clamp	(SUB FOR AR48236)
22.	R26287	[4]	O-Ring
23.	T130279	[2]	Elbow Fitting
24.	T77814	[6]	O-Ring
25.	AT168206	[1]	Hydraulic Hose - Fabricate	(SUB FOR AT150290)
26.	AT168206	[1]	Hydraulic Hose - Fabricate	(SUB FOR AT150290)
27.	14M7273	[1]	Nut	M8
28.	24M7238	[1]	Washer	8.700 X 17 X 2 MM
29.	R27491	[1]	Clamp
30.	19M7932	[1]	Cap Screw	M8 X 16
31.	38H1524	[1]	Elbow Fitting
32.	38H1166	[1]	Adapter Fitting	(STRAIGHT)
33.	........	[1]	Line	( AT150479 NO LONGER AVAILABLE) (SUB AT172102)
34.	........	[1]	Line	( AT149701 NO LONGER AVAILABLE) (SUB AT172103)
