约翰迪尔零件查询300D - BACKHOE, LOADER Battery Box ( - 814526)EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 370 次

Pos.	Part No	Qty	Parts name	Comments
1A.	........	[1]	Cover	( AT150118 NO LONGER AVAILABLE) (SUB T145883 AND T145884)
1A.	........	[1]	Cover	( AT151010 - NO LONGER AVAILABLE) (SUB T142604, T142603, (2) 03M7183, (2) 14M7273 AND (2) 24M7207)
1B.	........	[1]	Cover	( T145449 NO LONGER AVAILABLE) (SUB T145883 AND T145884)
1B.	T145883	[1]	Cover
2A.	........	[1]	Battery Box	( AT150659 NO LONGER AVAILABLE) (SUB AT158459, AT151812 AND T144181)
2B.	........	[1]	Battery Box	( AT158459 USE IF AVAILABLE) (SUB AT162711 AND T147679)
2B.	AT162711	[1]	Battery Box	(ALSO ORDER T147679)
3.	24M7296	[9]	Washer	10.500 X 30 X 2.500 MM
4.	19M7938	[4]	Cap Screw	M10 X 20
5.	24M7296	[3]	Washer	10.500 X 30 X 2.500 MM STEEL
5.	T145936	[3]	Washer	9.910 X 32 X 1.570 MM (0.390" X 1.260" X 1/16") NYLON
6.	19M7938	[3]	Cap Screw	M10 X 20
7.	03M7183	[2]	Bolt	M8 X 16
8.	24M7207	[2]	Washer	8.400 X 24 X 2 MM
9.	........	[1]	Cover	( T142603 NO LONGER AVAILABLE) (SUB T145884 AND T145883)
9.	T145884	[1]	Cover
10.	14M7273	[2]	Nut	M8
11.	AT151812	[1]	Lock
12.	........	[1]	Tray	( T144181 NO LONGER AVAILABLE) (SUB T147679)
12.	T147679	[1]	Tray
13.	M68997	[1]	Bumper
14.	19M7402	[5]	Cap Screw	M10 X 25
