| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1A. | AT13740 | [1] | Drain Valve | (WITHOUT ENGINE COOLANT HEATER) |
| 1A. | 15H613 | [1] | Elbow Fitting | 90° 1/4" (WITH ENGINE COOLANT HEATER) |
| 1B. | R55233 | [1] | Pipe Plug | (WITHOUT COOLANT HEATER) |
| 2. | 15H690 | [AR] | Pipe Plug | 3/4" |
| 2. | 15H562 | [AR] | Pipe Plug | 1" |
| 3. | R48685 | [2] | Dowel Pin | (SUB FOR R26241, THIS APPLICATION) |
| 4. | 15H275 | [AR] | Pipe Plug | 1/4", (WITHOUT COOLANT HEATER) |
| 4. | T29388 | [AR] | Union Fitting | (WITH ENGINE COOLANT HEATER) |
| 5. | R39741 | [1] | Drain Plug | (WITHOUT ENGINE COOLANT HEATER) |
| 6. | R122226 | [2] | Stud | (SUB FOR R122226) TIMING GEAR COVER |
| 6. | T25701 | [1] | Stud | WATER PUMP |
| 7. | 12H304 | [3] | Lock Washer | 3/8" |
| 8. | 14H1076 | [3] | Nut | 3/8" |
| 9. | T18891 | [2] | Plug | |
| 10. | R26493 | [1] | Bushing | OIL PRESSURE RELIEF VALVE |
| 11. | R26650 | [2] | Dowel Pin | |
| 12. | 15H666 | [1] | Pipe Plug | 3/8" |
| 13. | R48685 | [2] | Dowel Pin | (SUB FOR A120R) |
| 14. | R54802 | [3] | Orifice | |
| 14. | 22H932 | [3] | Set Screw | 5/16" X 3/8" |
| 15. | R79089 | [1] | Cap | (SUB FOR AR82295) |
| 16. | R65215 | [3] | Bearing Cap | (SUB FOR AR82294) |
| 17. | T20168 | [8] | Washer | |
| 18. | T23474 | [8] | Cap Screw | |
| 19. | 15H558 | [4] | Pipe Plug | 1/8", (SUB FOR RE12310) |
| 20. | R73139 | [1] | Flow Control Hyd. Valve | |
| 21. | R46625 | [1] | Spring | |
| 22. | R75892 | [AR] | O-Ring | (OIL PUMP TUBE) |
| 23. | T23435 | [1] | Threaded Nipple | |
| 24. | U13639 | [1] | O-Ring | (WITHOUT ENGINE COOLANT HEATER) |
| 25. | AR64724 | [1] | Cylinder Block | WITH MAIN BEARING CAPS, OIL FILTER NIPPLE, PIPE PLUGS, DOWEL PINS, STUDS, CAP SCREWS, WASHERS AND OIL PRESSURE RELIEF VALVE BUSHING, (MARKED R55120 OR R72965) (SUB RE19841) (DIESEL) |
| 25. | ........ | [1] | Cylinder Block | WITH MAIN BEARING CAPS, OIL FILTER NIPPLE, PIPE PLUGS, DOWEL PINS, STUDS, CAP SCREWS, WASHERS AND OIL PRESSURE RELIEF VALVE BUSHING, (MARKED R80408) (SUB FOR AR97026, MARKED R72965) ( RE19844 NO LONGER AVAILABLE) |
| 25. | ........ | [1] | Cylinder Block | WTH MAIN BEARING CAPS, OIL FILTER NIPPLE, PIPE PLUGS, DOWEL PINS, STUDS, CAP SCREWS, WASHERS AND OIL PRESSURE RELIEF VALVE BUSHING, (MARKED R72966) (SUB FOR AT31580, MARKED T32347 AND AR97074, MARKED R72966) (GASOLINE) ( RE19844 NO LONGER AVAILABLE) |
| ... | RE19842 | [1] | Short Block Assembly | CYLINDER BLOCK ASSEMBLY, WITH CRANKSHAFT, CAMSHAFT, IDLER GEAR, CONNECTING RODS, PISTONS, CYLINDER LINERS, TAPPETS, BYPASS VALVE, BYPASS SPRING, FRONT PLATE AND FRONT PLATE SET SCREWS, (SUB FOR AR97035 AND AR64730) (ALSO ORDER R81513, AR67942 AND RE4 |
| ... | ........ | [1] | Short Block Assembly | CYLINDER BLOCK ASSEMBLY, WITH CRANKSHAFT, CAMSHAFT, IDLER GEAR, CONNECTING RODS, PISTONS, CYLINDER LINERS, UPPER IDLER GEAR SHAFT, TAPPETS, FRONT PLATE AND FRONT PLATE SET SCREWS, (SUB FOR AR53364 AND AR97075) (ALSO ORDER R81513, AR67942, RE44574 AND |
