约翰迪尔零件查询302A - BACKHOE, LOADER REPLACEMENT CYLINDER HEAD, HEAD GASKET AND VALVES [01B08]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 178 次

Pos.	Part No	Qty	Parts name	Comments
1.	R53223	[14]	Cap Screw
2.	T20168	[14]	Washer
3.	T20129	[6]	Cap
4.	T20077	[12]	Retainer
5.	T20176	[6]	Retainer
6.	R26125	[6]	Spring
7.	A3910R	[2]	Plug
8.	R51734	[3]	Valve Seat Insert	EXHAUST
9.	R87627	[6]	O-Ring
10.	R79624	[3]	Exhaust Valve	STANDARD, (SUB FOR R52252)
10.	R79625	[AR]	Exhaust Valve	0.08 MM (.003") OVERSIZE, (SUB FOR R57333)
10.	R79626	[AR]	Exhaust Valve	0.38 MM (.015") OVERSIZE
10.	........	[AR]	Exhaust Valve	( R79627 NO LONGER AVAILABLE) 0.76 MM (.030") OVERSIZE, (SUB FOR R57337)
11.	R79623	[3]	Intake Valve	STANDARD, (SUB FOR R52251)
11.	R79628	[AR]	Intake Valve	0.08 MM (.003") OVERSIZE, (SUB FOR R57332)
11.	R79629	[AR]	Intake Valve	0.38 MM (.015") OVERSIZE
11.	........	[AR]	Intake Valve	( R79630 NO LONGER AVAILABLE) 0.76 MM (.030") OVERSIZE, (SUB FOR R57336)
12.	R80241	[1]	Gasket	(USE IF AVAILABLE)
12.	R97356	[1]	Engine Cylinder Head Gasket	(SUB FOR R80241)
13.	AR70583	[1]	Cylinder Head	ASSY
