Pos.	Part No	Qty	Parts name	Comments
1.	RE24959	[1]	Seal	(USE IF AVAILABLE) REAR, (SUB FOR AT22965, AR92893 AND RE17831)
1.	RE44574	[1]	Seal	(SUB FOR RE24959)
2.	R48685	[1]	Dowel Pin	(SUB FOR A120R)
3.	T26324	[2]	Thrust Washer	INNER
4.	R89824	[1]	Shaft	(SUB FOR T26323)
5.	RE46896	[1]	Crankshaft	(MARKED R100142 (WITH BEARINGS AND OIL SEALS) (SUB FOR AT18031,MARKED T23516)
6.	34H283	[1]	Spring Pin	3/16" X 1-1/8"
7.	AR91660	[1]	Gear	UPPER, (MARKED R70182) (SUB FOR AT18009) (MARKED T20029) (55 TEETH)
8.	T20034	[1]	Bushing
9.	T26326	[2]	Thrust Washer	OUTER
10.	T26327	[1]	Screw
11.	26H72	[1]	Shaft Key	1/8" X 5/8"
12.	T20094	[1]	Helical Gear	(24 TEETH)
13.	T20046	[1]	Oil Slinger
14.	AR67942	[1]	Seal
15.	R59915	[1]	Pulley	(SUB FOR T25366 AND R47438)
16.	T20217	[1]	Washer
17.	19H2993	[1]	Cap Screw	1/2" X 1-1/2"
18A.	T26325	[2]	Screw
18B.	19H3183	[1]	Cap Screw	HS, SAE 8, 1/2" X 2-1/8"
19.	T26321	[1]	Bushing
20.	AT24252	[1]	Gear	LOWER, (MARKED T26322) (45 TEETH)
21.	34H286	[1]	Spring Pin	3/16" X 1-1/2"
22.	T23604	[1]	Shaft Key
23A.	R76126	[2]	Washer	(SUB FOR R42364)
23B.	R100105	[1]	Washer
24.	T20445	[1]	Plug	(WITHOUT REVERSER)
25.	T26323	[1]	Shaft
25.	R89824	[1]	Shaft
26.	14H865	[1]	Nut	1/2"
