约翰迪尔零件查询302A - BACKHOE, LOADER TIMING GEAR COVER (DIESEL) [01C03]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
598 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
R122226
|
[2] |
Stud
|
|
| 2. |
24H1304
|
[AR] |
Washer
|
|
| 3. |
14H812
|
[2] |
Nut
|
|
| 4. |
19H3065
|
[5] |
Cap Screw
|
|
| 5. |
R78366
|
[1] |
Gasket
|
|
| 6. |
R126041
|
[1] |
Cover
|
|
| 7. |
19H2284
|
[3] |
Cap Screw
|
|
| 7. |
R124277
|
[2] |
Cap Screw
|
|
| 8. |
T20273
|
[1] |
Gasket
|
|
| 9. |
T20272
|
[1] |
Cover
|
|
| 10. |
19H1726
|
[1] |
Cap Screw
|
|
| 11. |
T27657
|
[1] |
Fitting Plug
|
|
| 12. |
A4827R
|
[1] |
Washer
|
|
| 13. |
24H1290
|
[AR] |
Washer
|
|
| 14. |
T27658
|
[1] |
Spring
|
|
| 15. |
R83169
|
[1] |
Valve
|
|
| 16. |
19H3031
|
[2] |
Cap Screw
|
|
| 17. |
19H1801
|
[4] |
Cap Screw
|
|
| 18. |
AR58196
|
[1] |
Cover
|
|
| 19. |
T20155
|
[1] |
Gasket
|
|
