现代零件查询25/30/33G-7A CARRIAGE & B/REST (TF-MAST,30/33G-7A)EPC Hyundai _现代Hyundai_工程机械

现代零件查询25/30/33G-7A CARRIAGE & B/REST (TF-MAST,30/33G-7A)EPC Hyundai

广数供应链运营团队, 16 02月, 2025，浏览： 1004 次

Pos.	Part No	Qty	Parts name	Comments
1.	63HN-26010	[1]	CARR & B/REST SUB ASSY	SINGLE,30G-7A
1.	63HN-26011	[1]	CARR & BKR SUB ASSY	SINGLE,30G-7A
1.	63HN-26012	[1]	CARR & B/REST SUB ASSY	SINGLE,30,JK
1.	69HN-35010	[1]	CARR & B/REST SUB ASSY	SINGLE,33G-7A
1.	69HN-35011	[1]	CARR & B/REST SUB ASSY	SINGLE,33,JK
1.	63HN-26020	[1]	CARR & B/REST SUB ASSY	DOUBLE,30G-7A
1.	63HN-26021	[1]	CARR & BKR SUB ASSY	DOUBLE,30G-7A
1.	63HN-26022	[1]	CARR & B/REST SUB ASSY	DOUBLE,30,JK
1.	69HN-35020	[1]	CARR & B/REST SUB ASSY	DOUBLE,33G-7A
1.	69HN-35021	[1]	CARR & B/REST SUB ASSY	DOUBLE,33,JK
1.	63HN-26030	[1]	CARR & B/REST SUB ASSY	WIDE-S,30G-7A
1.	63HN-26031	[1]	CARR & BKR SUB ASSY	WIDE-S,30G-7A
1.	63HN-26032	[1]	CARR & B/REST SUB ASSY	WIDE-S,30,JK
1.	69HN-35030	[1]	CARR & B/REST SUB ASSY	WIDE-S,33G-7A
1.	69HN-35031	[1]	CARR & B/REST SUB ASSY	WIDE-S,33,JK
1.	63HN-26011	[1]	CARR & BKR SUB ASSY	30,SINGLE,STD
1.	63HN-26021	[1]	CARR & BKR SUB ASSY	30,DOUBLE,STD
1.	63HN-26031	[1]	CARR & BKR SUB ASSY	30,WIDE,STD
1.	69HN-35010	[1]	CARR & B/REST SUB ASSY	33,SINGLE,STD
1.	69HN-35020	[1]	CARR & B/REST SUB ASSY	33,DOUBLE,STD
1.	69HN-35030	[1]	CARR & B/REST SUB ASSY	33,WIDE,STD
1-1.	63HN-22011	[1]	CARRIAGE WA	SINGLE,30G-7A
1-1.	63HN-22012	[1]	CARRIAGE WA	SINGLE,30G-7A
1-1.	63HN-22013	[1]	CARRIAGE WA	SINGLE,30,JK
1-1.	69HN-31011	[1]	CARRIAGE WA	SINGLE,33G-7A
1-1.	69HN-31012	[1]	CARRIAGE WA	SINGLE,33,JK
1-1.	63HN-22021	[1]	CARRIAGE WA	DOUBLE,30G-7A
1-1.	63HN-22022	[1]	CARRIAGE WA	DOUBLE,30G-7A
1-1.	63HN-22023	[1]	CARRIAGE WA	DOUBLE,30,JK
1-1.	69HN-31021	[1]	CARRIAGE WA	DOUBLE,33G-7A
1-1.	69HN-31022	[1]	CARRIAGE WA	DOUBLE,33,JK
1-1.	63HN-22031	[1]	CARRIAGE WA	WIDE-S,30G-7A
1-1.	63HN-22032	[1]	CARRIAGE WA	WIDE-S,30G-7A
1-1.	63HN-22033	[1]	CARRIAGE WA	WIDE-S,30,JK
1-1.	69HN-31031	[1]	CARRIAGE WA	WIDE-S,33G-7A
1-1.	69HN-31032	[1]	CARRIAGE WA	WIDE-S,33,JK
1-1.	63HN-22012	[1]	CARRIAGE WA	30,SINGLE,STD
1-1.	63HN-22022	[1]	CARRIAGE WA	30,DOUBLE,STD
1-1.	63HN-22032	[1]	CARRIAGE WA	30,WIDE,STD
1-1.	69HN-31011	[1]	CARRIAGE WA	33,SINGLE,STD
1-1.	69HN-31021	[1]	CARRIAGE WA	33,DOUBLE,STD
1-1.	69HN-31031	[1]	CARRIAGE WA	33,WIDE,STD
1-2.	6AHN-24431	[1]	BACKREST WA	SINGLE
1-2.	6AHN-24631	[1]	BACKREST WA	DOUBLE
1-2.	6AHN-24731	[1]	BACKREST WA	WIDE-S
1-3.	S017-120356	[4]	BOLT-HEX
1-4.	S441-12000B	[4]	WASHER-HARDENED
2.	63HK-18100	[6]	LOAD R/BRG ASSY(117.5)	30,STD
2.	63HK-18101	[6]	LOAD R/BEARING(117.5)	30,STD
2.	63HK-18100	[6]	LOAD R/BRG ASSY(117.5)	33,STD
2.	63HK-18101	[6]	LOAD R/BEARING(117.5)	33,STD
2.	63HK-18110	[6]	LOAD R/BRG ASSY(117.2)	30,UNDERSIZE
2.	63HK-18111	[6]	LOAD R/BEARING(117.2)	30,UNDERSIZE
2.	63HK-18110	[6]	LOAD R/BRG ASSY(117.2)	33,UNDERSIZE
2.	63HK-18111	[6]	LOAD R/BEARING(117.2)	33,UNDERSIZE
2.	63HK-18120	[6]	LOAD R/BRG ASSY(117.8)	30,OVERSIZE
2.	63HK-18121	[6]	LOAD R/BEARING(117.8)	30,OVERSIZE
2.	63HK-18120	[6]	LOAD R/BRG ASSY(117.8)	33,OVERSIZE
2.	63HK-18121	[6]	LOAD R/BEARING(117.8)	33,OVERSIZE
2.	63HK-18130	[6]	LOAD R/BRG ASSY(116.9)	30,SMALLSIZE
2.	63HK-18141	[6]	LOAD R/BEARING(118.1)	30,LARGESIZE
2.	63HK-18130	[6]	LOAD R/BRG ASSY(116.9)	33,SMALLSIZE
2.	63HK-18141	[6]	LOAD R/BEARING(118.1)	33,LARGESIZE
3.	6600187900	[6]	SHIM(0.5T)
4.	6600188000	[6]	SHIM(1.0T)
5.	61F7-28010	[2]	BOLT-FLAT HD
6.	61F7-28021	[2]	WASHER-RETAINING
7.	61F7-28100	[4]	SIDE ROLLER ASSY	30G-7A
7.	61F7-28100	[2]	SIDE ROLLER ASSY	30G-7A
7.	61F7-28100	[4]	SIDE ROLLER ASSY	33G-7A
8.	61HM-28040	[8]	ADJUSTABLE SCREW	30G-7A
8.	61HM-28040	[4]	ADJUSTABLE SCREW	30G-7A
8.	61HM-28040	[8]	ADJUSTABLE SCREW	33G-7A
9.	S205-16100B	[8]	NUT-HEX	30G-7A
9.	S205-16100B	[4]	NUT-HEX	30G-7A
9.	S205-16100B	[8]	NUT-HEX	33G-7A
10.	S109-120206	[1]	BOLT-SOCKET
11.	65FS-21380	[2]	BUSHING	30G-7A
12.	S111-120356	[2]	SCREW-SET HEX SOCKET	30G-7A
13.	65FS-21410	[2]	BACK PLATE	30G-7A
14.	S205-12100B	[2]	NUT-HEX	30G-7A
