现代零件查询25/30/33G-7A INTEGRAL SIDE SHIFT (TF,30/33G-7A)EPC Hyundai _现代Hyundai_工程机械

现代零件查询25/30/33G-7A INTEGRAL SIDE SHIFT (TF,30/33G-7A)EPC Hyundai

广数供应链运营团队, 16 02月, 2025，浏览： 976 次

Pos.	Part No	Qty	Parts name	Comments
1.	@	[1]	INTEGRAL SIDE SHIFT ASSY	SEE 7255
2.	6AHN-24431	[1]	BACKREST WA	SINGLE
2.	6AHN-24631	[1]	BACKREST WA	DOUBLE
2.	6AHN-24731	[1]	BACKREST WA	WIDE-S
3.	63HK-18100	[6]	LOAD R/BRG ASSY(117.5)	30,STD
3.	63HK-18101	[6]	LOAD R/BRG ASSY	30,STD
3.	63HK-18100	[6]	LOAD R/BRG ASSY(117.5)	33,STD
3.	63HK-18101	[6]	LOAD R/BRG ASSY	33,STD
3.	63HK-18110	[6]	LOAD R/BRG ASSY(117.2)	30,UNDERSIZE
3.	63HK-18111	[6]	LOAD R/BRG ASSY	30,UNDERSIZE
3.	63HK-18110	[6]	LOAD R/BRG ASSY(117.2)	33,UNDERSIZE
3.	63HK-18111	[6]	LOAD R/BRG ASSY	33,UNDERSIZE
3.	63HK-18120	[6]	LOAD R/BRG ASSY(117.8)	30,OVERSIZE
3.	63HK-18121	[6]	LOAD R/BRG ASSY	30,OVERSIZE
3.	63HK-18120	[6]	LOAD R/BRG ASSY(117.8)	33,OVERSIZE
3.	63HK-18121	[6]	LOAD R/BRG ASSY	33,OVERSIZE
3.	63HK-18130	[6]	LOAD R/BRG ASSY(116.9)	30,SMALLSIZE
3.	63HK-18131	[6]	LOAD R/BRG ASSY	30,SMALLSIZE
3.	63HK-18130	[6]	LOAD R/BRG ASSY(116.9)	33,SMALLSIZE
3.	63HK-18131	[6]	LOAD R/BRG ASSY	33,SMALLSIZE
4.	6600187900	[6]	SHIM(0.5T)
5.	6600188000	[6]	SHIM(1.0T)
6.	61F7-28010	[2]	BOLT-FLAT HD
7.	61F7-28021	[2]	WASHER-RETAINING
8.	61F7-28100	[4]	SIDE ROLLER ASSY
9.	61HM-28040	[8]	ADJUSTABLE SCREW
10.	S205-16100B	[8]	NUT-HEX
11.	S017-120356	[4]	BOLT-HEX
12.	S441-12000B	[4]	WASHER-HARDENED
