约翰迪尔零件查询302A - BACKHOE, LOADER FOOT THROTTLE ASSEMBLY [01C13]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
700 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
M1339T
|
[1] |
Spacer
|
|
| 2. |
L4667T
|
[1] |
Pin Fastener
|
|
| 2. |
R662R
|
[1] |
Pin Fastener
|
|
| 3. |
M3742T
|
[1] |
Yoke
|
|
| 4. |
14H649
|
[1] |
Nut
|
|
| 5. |
T22149
|
[1] |
Rod
|
|
| 6. |
T50467
|
[1] |
Spring
|
|
| 7. |
T22150
|
[1] |
Arm
|
|
| 8. |
F3396R
|
[1] |
Snap Ring
|
|
| 9. |
T22240
|
[1] |
Arm
|
|
| 10. |
T26937
|
[1] |
Cap
|
|
| 11. |
11M7077
|
[1] |
Cotter Pin
|
|
| 11. |
11H234
|
[1] |
Cotter Pin
|
|
| 12. |
24H1286
|
[2] |
Washer
|
|
| 13. |
19H1765
|
[1] |
Cap Screw
|
|
| 14. |
24H1305
|
[1] |
Washer
|
|
| 15. |
AR94952
|
[1] |
Pedal
|
|
