约翰迪尔零件查询302A - BACKHOE, LOADER RADIATOR (WITH OIL COOLER) [01C18]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 560 次

Pos.	Part No	Qty	Parts name	Comments
1.	T11234	[2]	Lock Nut
2.	24H1305	[2]	Washer	13/32" X 13/16" X 0.065"
3.	R61460	[1]	Rod	(SUB FOR T22495)
4.	24H1122	[1]	Washer	3/8" X 7/8" X 0.083"
5.	19H2664	[1]	Cap Screw	5/16" X 3/4"
6.	AT27585	[1]	Cap
7.	AT28810	[1]	Radiator
8.	14H785	[5]	Nut	5/16"
9.	12H303	[5]	Lock Washer	5/16"
10.	24H1685	[4]	Washer	11/32" X 47/64" X 0.083"
11.	AT20848	[1]	Oil Cooler	(SUB AT169229)
11.	AT169229	[1]	Oil Cooler	(SUB FOR AR69398 AND AT77459 OR AT165535)
12.	T22900	[1]	Deflector
13.	T21690	[1]	Shroud
14.	AR21999	[4]	Hose Clamp	(SUB FOR AR21840)
15.	T23533	[1]	Hose	(DIESEL)
15.	R38481	[1]	Hose	(DIESEL) (SUB FOR R38312)
15.	T22496	[1]	Hose	(GASOLINE)
16.	T22500	[1]	Hose
17.	37H79	[4]	Screw	1/4" X 5/8"
18.	19H2458	[2]	Cap Screw	3/8" X 3"
19.	R62372	[2]	Spring	(SUB FOR R34352)
20.	T22381	[2]	Washer
21.	T22375	[1]	Pad
22.	AT13740	[1]	Drain Valve
23.	R35339	[1]	Isolator
...	T11847	[1]	Sealant	(NO LONGER AVAILABLE)
