Pos.	Part No	Qty	Parts name	Comments
1.	T29540	[1]	Fitting	(SUB R79604)
2.	T29539	[1]	Washer	(SUB R79605)
3A.	AT27622	[1]	Cap
3B.	AR85618	[1]	Cap	(SUB R79604, R79605 AND R79606)
4.	........	[1]	Nut	( R47733 NO LONGER AVAILABLE)
5.	........	[1]	Screw	( R47732 NO LONGER AVAILABLE)
6.	........	[1]	Screw	( R47734 NO LONGER AVAILABLE)
7.	........	[1]	Nut	( R46675 NO LONGER AVAILABLE)
8.	........	[1]	Spring	( R47731 NO LONGER AVAILABLE)
9.	........	[1]	Valve Seat	( R39886 NO LONGER AVAILABLE)
10.	T26870	[1]	Clamp	(SUB R67779)
10.	R67779	[1]	Clamp
11.	R34764	[1]	Washer	(K1) UPPER, (USE WITH AR56290) (SUB RE13887, THIS APPLICATION) (SUB RE32011)
11.	R60746	[1]	Washer	(K) UPPER, (USE WITH AR73673 AND AR88239) (USE AFTER RE13887 HAS BEEN INSTALLED)
12.	R48000	[1]	Seal	LOWER
13.	T24472	[1]	Cap
14.	AR56290	[1]	Injection Nozzle	(ROOSA-MASTER NOS. 19762 OR 20500) (SUB AR89564)
14.	AR73673	[1]	Injection Nozzle	(ROOSA-MASTER NO. 20631) (SUB AR89564)
14.	AR88239	[1]	Injection Nozzle	(ROOSA-MASTER NO. 22042) (SUB AR89564)
14.	SE500822	[1]	Nozzle	(PKG 4-REMANUFACTURED FOR AR89564)
14.	SE501099	[1]	Nozzle	(REMAN FOR AR89564- PKG 1)
15.	R34760	[1]	Clamp
16.	R34761	[1]	Spacer	(K1) (SUB RE13887, THIS APPLICATION) (SUB RE32011)
16.	R60745	[1]	Spacer	(K) (USE AFTER RE13887 HAS BEEN INSTALLED)
17.	........	[1]	Cap (Hat)	( T31174 NO LONGER AVAILABLE) (USE FOR SERVICING FUEL INJECTION NOZZLE)
