约翰迪尔零件查询302A - BACKHOE, LOADER FUEL INJECTION SYSTEM (ENGINE SERIAL NO. 505333- ) [01D18]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 357 次

Pos.	Part No	Qty	Parts name	Comments
1.	16H658	[1]	Rivet	1/4" X 5/8"
2.	R51937	[6]	Tube Nut
3.	R51936	[6]	Sealing Washer
4.	AR85618	[3]	Cap	(SUB R79604, R79605 AND R79606)
5.	R66090	[2]	Tube
6.	AR89839	[1]	Fuel Line
7.	T29969	[1]	Clamp
8.	R34761	[3]	Spacer	(K1) (SUB (3) RE13887, THIS APPLICATION) (SUB RE32011)
8.	R60745	[3]	Spacer	(K)
9.	R34760	[3]	Clamp
10.	AR88239	[3]	Injection Nozzle	(SUB AR89564)
10.	AR89564	[3]	Injection Nozzle
10.	SE500822	[1]	Nozzle	REMANUFACTURED FOR AR89564 - PKG 4
10.	SE501099	[1]	Nozzle	REMANUFACTURED FOR AR89564 - PKG 1
11.	R60746	[3]	Washer	(K) UPPER, (USE WITH AR88239) (SUB RE32011) (USE AFTER RE13887 HAS BEEN INSTALLED)
11.	R34764	[3]	Washer	(K1) UPPER, (USE WITH AR89564) (SUB (3) RE13887, THIS APPLICATION)
12.	R48000	[3]	Seal	LOWER
13.	R59297	[1]	Half Clamp
13.	R59298	[1]	Strap
14.	R59297	[1]	Half Clamp
14.	R61145	[1]	Strap
15.	AT18111	[1]	Fuel Line	NO. 3
16.	AT18099	[1]	Fuel Line	NO. 2
17.	R35352	[1]	Fitting
18.	AR76704	[2]	Screw
19.	T20055	[6]	Washer
20.	R26726	[3]	Hollow Screw
21.	14H812	[2]	Nut	3/8"
22.	12H304	[2]	Lock Washer	3/8"
23.	24M7096	[2]	Washer	0.413" X 0.709" X 0.063"
24.	T20052	[2]	Stud
25.	R84663	[1]	Gear	(SUB FOR T20165) (48 TEETH)
26.	R48599	[1]	Nut
27.	R132874	[1]	Washer	(SUB FOR R48600)
28.	26H10	[1]	Shaft Key	5/32" X 5/8"
29.	AR49904	[1]	Fuel Injection Pump	(ROOSA-MASTER NO. JDB331AL2406 OR JDB331MD2406)
30.	AT18065	[1]	Fuel Line	NO. 1
