Pos.	Part No	Qty	Parts name	Comments
1.	T20088	[1]	Gear	(142 TEETH)
2.	AR67976	[1]	Flywheel
3.	JD9449	[1]	Ball Bearing
4.	RE33891	[1]	Clutch Disk	(DIESEL) (SUB FOR AL24059)
4.	AT21665	[1]	Clutch Disk	(GASOLINE)
5.	AT17464	[1]	Thrust Bearing
6.	19H3483	[8]	Cap Screw	3/8" X 1-1/8"
7.	12H304	[8]	Lock Washer	3/8"
8.	AR69708	[1]	Seal	(SUB FOR AF1934R)
9.	T22178	[1]	Washer
10.	T22177	[1]	Support
11A.	T22505	[1]	Fork
11B.	T63651	[1]	Fork
12.	T22567	[2]	Pin Fastener
13A.	AT20055	[1]	Housing	CARRIER FOR THROW OUT BEARING, WITH PINS
13B.	AT60365	[1]	Roller Carriage
14.	L372T	[6]	Cap Screw
15.	12H303	[6]	Lock Washer	5/16"
16.	R27320	[1]	Bushing
17.	T24948	[1]	Spring
18.	34H253	[1]	Spring Pin	1/8" X 1-3/8"
19A.	AT27717	[1]	Shaft
19B.	AT60373	[1]	Shaft
20.	AR63785	[1]	Plate	(SUB FOR AT22064) (SUB AT60368)
20.	AT60368	[1]	Clutch Plate
21.	19H3385	[4]	Cap Screw	HS, SAE 8, 1/2" X 1-1/8", (SUB FOR R28029)
22A.	19H2552	[2]	Cap Screw	3/8" X 1-1/8"
22B.	H78097	[4]	Screw	(SUB FOR R49482)
