约翰迪尔零件查询302A - BACKHOE, LOADER TRANSMISSION OIL FILTER [01F14]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
585 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
R34733
|
[1] |
Sealing Washer
|
|
| 2. |
AR75603
|
[1] |
Filter Element
|
|
| 3. |
R32507
|
[1] |
Snap Ring
|
|
| 4. |
R28593
|
[1] |
Retainer
|
|
| 4. |
R65892
|
[1] |
Retainer
|
|
| 5. |
R394R
|
[1] |
O-Ring
|
|
| 6. |
24H1227
|
[1] |
Washer
|
|
| 7. |
R66064
|
[1] |
Spring
|
|
| 8. |
R39796
|
[1] |
Cover
|
|
| 9. |
R82731
|
[1] |
Screw
|
|
| 10. |
T31170
|
[1] |
Cover
|
|
| 11. |
U12547
|
[1] |
O-Ring
|
|
| 12. |
Y1912C
|
[1] |
Adapter Fitting
|
|
| 13. |
15H561
|
[1] |
Pipe Plug
|
|
| 14. |
AT30197
|
[1] |
Cover
|
|
| 15. |
R394R
|
[1] |
O-Ring
|
|
| 15. |
F2741R
|
[1] |
Packing
|
|
