约翰迪尔零件查询302A - BACKHOE, LOADER GEARS AND SHAFTS (SINGLE 540 RPM PTO) [01F22]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
558 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
T22128
|
[1] |
Bushing
|
|
| 2. |
T22127
|
[1] |
Bushing
|
|
| 3. |
AT23224
|
[1] |
Shaft
|
|
| 4. |
M2353T
|
[4] |
Snap Ring
|
|
| 5. |
T22214
|
[1] |
Gear
|
|
| 6. |
14H812
|
[4] |
Nut
|
|
| 7. |
R30958
|
[4] |
Lock Plate
|
|
| 8. |
T22234
|
[1] |
Bearing Housing W/O Bearing
|
|
| 9. |
T21997
|
[1] |
Gasket
|
|
| 10. |
R26656
|
[1] |
Washer
|
|
| 11. |
JD8877
|
[1] |
Needle Bearing
|
|
| 12. |
R47249
|
[1] |
Shaft
|
|
| 13. |
40M7044
|
[1] |
Snap Ring
|
|
| 14. |
JD9344
|
[1] |
Ball Bearing
|
|
| 15. |
AL56820
|
[1] |
Seal
|
|
| 16. |
T22080
|
[1] |
Gasket
|
|
| 17. |
R47514
|
[1] |
Bearing Housing W/O Bearing
|
|
| 18. |
12H301
|
[3] |
Lock Washer
|
|
| 19. |
19H2993
|
[3] |
Cap Screw
|
|
| 20. |
R27329
|
[2] |
Screw
|
|
