约翰迪尔零件查询302A - BACKHOE, LOADER REAR AXLE HOUSING AND SHAFT [01G03]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
726 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
T24519
|
[1] |
Spindle
|
|
| 2. |
AT20703
|
[1] |
Seal
|
|
| 3. |
L35542
|
[1] |
Guide
|
|
| 4. |
JD8946
|
[1] |
Bearing Cone
|
|
| 5. |
JD8206
|
[1] |
Bearing Cup
|
|
| 6. |
JD7759
|
[1] |
Lubrication Fitting
|
|
| 7. |
R27216
|
[1] |
Drain Plug
|
|
| 8. |
R26287
|
[1] |
O-Ring
|
|
| 9. |
19H1805
|
[11] |
Cap Screw
|
|
| 9. |
19H1805
|
[9] |
Cap Screw
|
|
| 9. |
19H3057
|
[2] |
Cap Screw
|
|
| 10. |
R21612
|
[1] |
Bleed Valve
|
|
| 11. |
AR68402
|
[1] |
Housing
|
|
| 12. |
T21428
|
[3] |
Dowel Pin
|
|
| 13. |
R98915
|
[1] |
Gasket
|
|
| 14. |
AT124397
|
[1] |
Seal
|
|
| 15. |
JD8206
|
[1] |
Bearing Cup
|
|
| 16. |
JD9007
|
[1] |
Bearing Cone
|
|
| 17. |
R47862
|
[1] |
Cap
|
|
