约翰迪尔零件查询302A - BACKHOE, LOADER ROCKSHAFT, PISTON AND LIFT ARMS [01G16]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
561 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
19H2898
|
[2] |
Cap Screw
|
|
| 2. |
T21956
|
[2] |
Washer
|
|
| 3. |
T29931
|
[2] |
Lift Arm
|
|
| 4. |
L41932
|
[1] |
Rockshaft
|
|
| 5. |
T21474
|
[1] |
Lever
|
|
| 6. |
34H320
|
[1] |
Spring Pin
|
|
| 7. |
F2570R
|
[1] |
Rod
|
|
| 8. |
R47344
|
[1] |
Piston
|
|
| 8. |
R65619
|
[1] |
Piston
|
|
| 9. |
A4444R
|
[1] |
O-Ring
|
|
| 9. |
R65621
|
[1] |
Washer
|
|
| 9. |
R65621
|
[1] |
Washer
|
|
| 10. |
T21617
|
[1] |
Back-Up Ring
|
|
| 10. |
R65620
|
[1] |
Washer
|
|
| 10. |
R65620
|
[1] |
Washer
|
|
| 11. |
T22319
|
[1] |
Cam
|
|
| 12. |
19H2151
|
[1] |
Cap Screw
|
|
| 13. |
T28362
|
[1] |
Spacer
|
|
