约翰迪尔零件查询302A - BACKHOE, LOADER HYDRAULIC OIL RESERVOIR (WITHOUT REVERSER) [01H11]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
381 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
T22970
|
[1] |
Plug
|
|
| 2. |
U11343
|
[2] |
O-Ring
|
|
| 3. |
AT20983
|
[1] |
Fitting
|
|
| 4. |
D2361R
|
[1] |
Ball
|
|
| 5. |
R39078
|
[1] |
Spring
|
|
| 6. |
R39076
|
[1] |
Guide
|
|
| 7. |
AR21839
|
[4] |
Clamp
|
|
| 8. |
........
|
[1] |
Hydraulic Hose
|
|
| 9. |
T30104
|
[1] |
Tube
|
|
| 10. |
R27531
|
[4] |
Clamp
|
|
| 11. |
24M7055
|
[2] |
Washer
|
|
| 12. |
37H84
|
[2] |
Screw
|
|
| 13. |
........
|
[1] |
Hydraulic Hose
|
|
| 14. |
R39215
|
[1] |
Fitting
|
|
| 15. |
........
|
[1] |
Hydraulic Hose
|
|
| 16. |
19H1648
|
[2] |
Cap Screw
|
|
| 17. |
12H304
|
[3] |
Lock Washer
|
|
| 18. |
19H2021
|
[1] |
Cap Screw
|
|
| 19. |
AR63288
|
[1] |
Reservoir
|
|
| 20. |
AT20960
|
[1] |
Oil Line
|
|
| 21. |
H2742B
|
[2] |
Clamp
|
|
