约翰迪尔零件查询302A - BACKHOE, LOADER SELECTIVE CONTROL VALVE COVER AND ROCKER [01H23]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
191 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
T22996
|
[1] |
Adjusting Strap
|
|
| 2. |
14H732
|
[2] |
Nut
|
|
| 3. |
R39225
|
[2] |
Stud
|
|
| 4. |
12H304
|
[4] |
Lock Washer
|
|
| 5. |
19H2676
|
[2] |
Cap Screw
|
|
| 6. |
R49186
|
[1] |
Cover
|
|
| 7. |
R49187
|
[1] |
Washer
|
|
| 8. |
R51414
|
[1] |
Cam
|
|
| 9. |
R49221
|
[2] |
Retainer
|
|
| 10. |
22H1025
|
[4] |
Set Screw
|
|
| 11. |
R56504
|
[1] |
Spring Pin
|
|
| 12. |
R51415
|
[1] |
Cam
|
|
| 13. |
R27233
|
[2] |
Screw
|
|
| 14. |
R51412
|
[1] |
Rocker
|
|
| 15. |
R51413
|
[1] |
Cam
|
|
| 16. |
R28744
|
[2] |
Pin
|
|
| 17. |
RE19419
|
[1] |
Lock
|
|
| 18. |
14H785
|
[1] |
Nut
|
|
| 19. |
RE19419
|
[1] |
Lock
|
|
| 20. |
T25804
|
[1] |
Lock Washer
|
|
| 21. |
24H1320
|
[1] |
Washer
|
|
| 22. |
T25803
|
[1] |
Cap Screw
|
|
| ... |
AT29222
|
[1] |
Lock
|
|
