约翰迪尔零件查询302A - BACKHOE, LOADER SINGLE AND DUAL SELECTIVE CONTROL VALVE COUPLERS [01I11]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 977 次

Pos.	Part No	Qty	Parts name	Comments
1.	R59633	[2]	Wear Ring	(A) (SUB AR93819, THIS APPLICATION)
2.	R28085	[2]	Guide	(A) (SUB AR93819, THIS APPLICATION)
3.	R28084	[2]	Spring	(A) (SUB AR93819, THIS APPLICATION)
4.	D2361R	[2]	Ball	(A) (SUB AR93819, THIS APPLICATION)
5.	R27430	[2]	Hyd. Quick-Connect Coupler	(A) (SUB AR93819, THIS APPLICATION)
6.	AR93819	[2]	HYDR.QUICK COUPLER PLUG	(A) WITHOUT DUST COVER (SUB FOR AR30210 WITH DUST COVER, THIS APPLICATION)
7.	R28006	[2]	Cap	(A)
8.	R32356	[2]	Snap Ring	(A)
9.	R32355	[2]	Sleeve	(A)
10.	R32354	[2]	Spring	(A)
11.	R26485	[2]	Back-Up Ring	(A)
12.	R495R	[2]	O-Ring	(A)
13.	400R	[12]	Ball	(A)
14.	R32353	[2]	Socket Outlet	(A)
15.	D2361R	[2]	Ball	(A)
16.	R28084	[2]	Spring	(A)
17.	R28085	[2]	Guide	(A)
18.	T22245	[1]	Clamp	(USED WITH DUAL SELECTIVE CONTROL VALVE)
19.	12H304	[2]	Lock Washer	3/8"
20.	19H1765	[2]	Cap Screw	3/8" X 1-3/4"
21.	19H2735	[3]	Cap Screw	1/2" X 2"
21.	19H1990	[3]	Cap Screw	1/2" X 2-1/4"
22.	19H2993	[1]	Cap Screw	1/2" X 1-1/2", (USED WITH SINGLE SELECTIVE CONTROL VALVE)
22.	19H2473	[1]	Cap Screw	1/2" X 1-3/4", (USED WITH SINGLE SELECTIVE CONTROL VALVE)
22.	19H3057	[1]	Cap Screw	1/2" X 2-3/4", (USED WITH DUAL SELECTIVE CONTROL VALVE)
22.	19H3057	[1]	Cap Screw	1/2" X 2-3/4", (USED WITH DUAL SELECTIVE CONTROL VALVE)
23.	R26375	[2]	O-Ring
24.	R27237	[2]	Fitting
25.	T22243	[1]	Clamp	R.H.
26.	T22244	[1]	Groove Pin
27.	R32419	[2]	Cover	(A)
28.	R59633	[2]	Wear Ring	(A)
29.	R36946	[2]	Spring	(A)
30.	T20168	[4]	Washer
...	AR31611	[1]	Coupling
