约翰迪尔零件查询302A - BACKHOE, LOADER REGULAR SEAT AND BACKHOE SWIVEL SEAT [01J23]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
329 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
19H1648
|
[13] |
Cap Screw
|
|
| 2. |
T22782
|
[1] |
Support
|
|
| 3. |
AT25964
|
[1] |
Cushion
|
|
| 4. |
T27718
|
[1] |
Support
|
|
| 5. |
T27719
|
[1] |
Support
|
|
| 6. |
AT20490
|
[1] |
Cushion
|
|
| 7. |
19H2898
|
[2] |
Cap Screw
|
|
| 8. |
M557T
|
[2] |
Washer
|
|
| 9. |
AT40628
|
[1] |
Support
|
|
| 10. |
R41778
|
[2] |
Bolt
|
|
| 11. |
24H1226
|
[4] |
Washer
|
|
| 12. |
24H1363
|
[2] |
Washer
|
|
| 13. |
12H293
|
[2] |
Lock Washer
|
|
| 14. |
14H813
|
[2] |
Nut
|
|
| 15. |
R81424
|
[1] |
Safety Sign
|
|
| 16. |
AT37833
|
[1] |
Seat Belt
|
|
| 16. |
AT38518
|
[1] |
Seat Belt
|
|
| 17. |
T30457
|
[1] |
Strap
|
|
