| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 19H1648 | [8] | Cap Screw | 3/8" X 3/4" |
| 2. | T27718 | [1] | Support | R.H. |
| 3. | AT25964 | [1] | Cushion | (BLACK) |
| 4. | T27719 | [1] | Support | L.H. |
| 5. | AT20490 | [1] | Cushion | (BLACK) |
| 6. | R41778 | [2] | Bolt | 7/16" X 1-1/4" |
| 7. | 24H1226 | [4] | Washer | 1/2" X 1-1/4" X 0.083" |
| 8. | 12H293 | [2] | Lock Washer | 7/16" |
| 9. | 14H813 | [2] | Nut | 7/16" |
| 10. | R81424 | [1] | Safety Sign | (SUB FOR R42732) |
| 11. | 24H1363 | [2] | Washer | 41/64" X 1-1/16" X 0.105" |
| 12. | AT37833 | [1] | Seat Belt | (SUB FOR AT24149) |
| 12. | AT38518 | [1] | Seat Belt | 76 MM WIDE (3") (COMPLIES WITH CALIFORNIA SAFETY CODE) |
