约翰迪尔零件查询302A - BACKHOE, LOADER LOADER BOOM [02D05]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
643 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
JD7759
|
[4] |
Lubrication Fitting
|
|
| 2. |
AU42183
|
[2] |
Pin Fastener
|
|
| 3. |
19H2855
|
[2] |
Cap Screw
|
|
| 3. |
T11234
|
[2] |
Lock Nut
|
|
| 4. |
U12817
|
[4] |
Bushing
|
|
| 5. |
BU40443
|
[1] |
Loader Boom
|
|
| 6. |
AU11658
|
[2] |
Pin
|
|
| 7. |
11H223
|
[2] |
Cotter Pin
|
|
| 8. |
U43298
|
[2] |
Pin
|
|
| 9. |
19H2458
|
[2] |
Cap Screw
|
|
| 9. |
T11234
|
[2] |
Lock Nut
|
|
| 10. |
19H3520
|
[2] |
Cap Screw
|
|
| 10. |
BP12214
|
[2] |
Lock Nut
|
|
| 11. |
AU11942
|
[2] |
Pin Fastener
|
|
| 12. |
T10671
|
[6] |
Cap Screw
|
|
| 13. |
JD5645
|
[2] |
Label
|
|
