约翰迪尔零件查询302A - BACKHOE, LOADER BACKHOE OIL LINES AND FITTINGS: MANIFOLD TO BOOM, CROWD AND BUCKET CYLINDER (9250 BACKHOE) [02E22]EPC John Deere online_约翰迪尔John Deere_工程机械

约翰迪尔零件查询302A - BACKHOE, LOADER BACKHOE OIL LINES AND FITTINGS: MANIFOLD TO BOOM, CROWD AND BUCKET CYLINDER (9250 BACKHOE) [02E22]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 279 次

Pos.	Part No	Qty	Parts name	Comments
1.	R26906	[5]	O-Ring
2.	R26375	[4]	O-Ring	(SUB FOR U10778)
3.	R26375	[2]	O-Ring
4.	AU42135	[2]	Hydraulic Hose - Fabricate	1422.4 MM (1/2" X 56" LONG) MANIFOLD TO BOOM CYLINDER
5.	TY3010	[1]	Hydraulic Hose	1143 MM (1/2" X 45" LONG) (SUB FOR AU10860 AND AU13295) L.H. CROWD TUBE
6.	AU10861	[1]	Hydraulic Hose - Fabricate	838.2 MM (1/2" X 33" LONG) (SUB FOR AU11506) L.H. BUCKET TUBE
7.	AU10861	[1]	Hydraulic Hose - Fabricate	838.2 MM (1/2" X 33" LONG) (SUB FOR AU11506) R.H. BUCKET TUBE
8.	AU10807	[1]	Hydraulic Hose - Fabricate	1066.8 MM (1/2" X 42" LONG) R.H. CROWD TUBE
9.	AU11753	[3]	Union Fitting
10.	AU11752	[1]	Fitting	90° (NOT USED WHEN AU10861 OR AU10810 HAS BEEN INSTALLED AS A REPLACEMENT PART FOR AU42219)
11.	AU42218	[2]	Hydraulic Hose - Fabricate	711 MM (1/2" X 28" LONG) (SUB AU11603 AND AU10810) CROWD TUBES TO CYLINDER
12.	U16163	[2]	Elbow Fitting	90° (NOT USED WHEN AU10861 OR AU10810 HAS BEEN INSTALLED AS A REPLACEMENT PART FOR AU42219)
12.	U16163	[2]	Elbow Fitting	90°
13.	14H863	[2]	Nut	3/4" (NOT USED WHEN AU10861 OR AU10810 HAS BEEN INSTALLED AS A REPLACEMENT PART FOR AU42219)
13.	14H863	[2]	Nut	3/4"
14.	AU42283	[1]	Tube	CROWD CYLINDER, L.H.
15.	AU42090	[2]	Oil Line	BUCKET CYLINDER
16.	AU42282	[1]	Tube	CROWD CYLINDER, R.H.
17.	AU11603	[2]	Hydraulic Hose - Fabricate	711 MM (1/2" X 28" LONG) BUCKET TUBES TO CYLINDER
18.	U11273	[1]	Elbow Fitting
19.	AU12217	[1]	Adapter Fitting
20.	U11009	[1]	Adapter Fitting
21.	19H2633	[1]	Cap Screw	3/8" X 1-1/2"
22.	12H304	[1]	Lock Washer	3/8"
23.	U40447	[1]	Clamp
24.	U10516	[1]	Hose Clamp
25.	T38967	[2]	Clamp
26.	T38968	[2]	Strap
27.	12H304	[2]	Lock Washer	3/8"
28.	T11234	[2]	Lock Nut
29.	AU11849	[4]	Adapter Fitting
30.	AH16917	[2]	Adapter Fitting
31.	AU11603	[1]	Hydraulic Hose - Fabricate	711 MM (1/2" X 28" LONG) (SUB FOR AU42218)
32.	AU10810	[1]	Hydraulic Hose - Fabricate	775 MM (1/2" X 28" LONG) (SUB FOR AU42218) (NOT USED WHEN AU10861 OR AU10810 HAS BEEN INSTALLED AS A REPLACEMENT PART FOR AU42219)
