约翰迪尔零件查询302A - BACKHOE, LOADER STANDARD BACKHOE BUCKETS 18 (457.2 MM), 24 (609.4 MM), 30 (762.0 MM), AND 36-INCH (914.4 MM) (9250 BEPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
296 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
U42744
|
[1] |
Cutting Edge
|
|
| 2. |
U42753
|
[1] |
Cutting Edge
|
|
| 2. |
U42752
|
[1] |
Cutting Edge
|
|
| 2. |
U42755
|
[1] |
Cutting Edge
|
|
| 3. |
U14436
|
[AR] |
Shank
|
|
| 4. |
U14437
|
[AR] |
Point
|
|
| 5. |
U42745
|
[1] |
Cutting Edge
|
|
| 6. |
........
|
[1] |
Backhoe Bucket
|
|
| 6. |
........
|
[1] |
Backhoe Bucket
|
|
| 6. |
........
|
[1] |
Backhoe Bucket
|
|
| 6. |
........
|
[1] |
Backhoe Bucket
|
|
| 7. |
........
|
[1] |
Plate
|
|
| 8. |
U42738
|
[2] |
Bushing
|
|
| 9. |
U42737
|
[4] |
Bushing
|
|
| 10. |
28H2239
|
[1] |
Spacer
|
|
| 11. |
U11651
|
[2] |
Washer
|
|
| 12. |
11H221
|
[4] |
Cotter Pin
|
|
| 13A. |
AU42426
|
[1] |
Pin Fastener
|
|
| 13B. |
T59459
|
[1] |
Pin Fastener
|
|
| 14. |
........
|
[1] |
Plate
|
|
| 15. |
U11649
|
[2] |
Washer
|
|
| 16A. |
AU42334
|
[1] |
Pin Fastener
|
|
| 16B. |
T59451
|
[1] |
Pin Fastener
|
|
| 17. |
AT36087
|
[1] |
Plate
|
|
| 18. |
........
|
[1] |
Tooth
|
|
| 19. |
T59447
|
[2] |
Snap Ring
|
|
| 20. |
T59452
|
[2] |
Snap Ring
|
|
