Pos.	Part No	Qty	Parts name	Comments
1.	JD7806	[1]	Lubrication Fitting
2.	U10745	[2]	Bushing
3.	AR89941	[1]	Hydraulic Cylinder Barrel
4.	R26906	[2]	O-Ring
5.	AU42120	[1]	Adapter Fitting
6.	R375R	[1]	O-Ring
7.	U42974	[1]	Back-Up Ring
8.	U42972	[1]	Sleeve
9.	........	[1]	Connector	(SUB AU42120)
10.	AT38049	[1]	Line
11.	22H1077	[1]	Set Screw	1/4" X 5/16"
12.	U43861	[1]	Lock Nut
13.	T39038	[1]	Piston
14.	T37381	[1]	Packing	(A) (SUB FOR R72830)
15.	R1138R	[1]	O-Ring	(A)
16.	T39037	[1]	Piston
17.	U44491	[2]	Piston Ring
18.	U17337	[1]	Wear Ring	(A)
19.	L2301CU	[1]	O-Ring	(A)
20.	L2309CU	[1]	Back-Up Ring	(A)
21.	N10193	[1]	Snap Ring
22.	R76801	[1]	Packing	(A) (SUB FOR T35850)
23.	U41578	[1]	Wear Ring	(A)
24.	R80935	[1]	Guide	(SUB FOR R68990)
25.	L2029CU	[1]	Seal	(A)
26.	AT38672	[1]	Rod
27.	JD7782	[1]	Lubrication Fitting
28.	15H666	[1]	Pipe Plug	3/8"
29.	AR89940	[1]	Hydraulic Cylinder	(INCLUDES RETURN TUBE)
...	RE18732	[1]	Hydraulic Cylinder Kit	(SUB FOR AT38582, AR96528 AND AR105386)
