约翰迪尔零件查询310 - BACKHOE, LOADER CYLINDER HEAD AND ROCKER ARM COVER [01B03]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 726 次

Pos.	Part No	Qty	Parts name	Comments
1.	T20074	[1]	Tube
2.	24H1685	[1]	Washer	11/32" X 47/64" X 0.083"
3.	19H1813	[1]	Cap Screw	5/16" X 5/8"
4.	AR103811	[6]	Screw With Washer	(SUB FOR AR45530, THIS APPLICATION) (SUB FOR AR100124)
5.	R40791	[1]	Clamp
6.	AR70582	[1]	Cylinder Head	(DIESEL) (MARKED R58685) (SUB FOR AT21789, MARKED T24755) (SUB FOR AR70583)
6.	AT21332	[1]	Cylinder Head	(GASOLINE) (MARKED T19974)
7.	A3910R	[2]	Plug
8.	R80241	[1]	Gasket	(USE IF AVAILABLE) (SUB FOR R59447)
8.	R97356	[1]	Engine Cylinder Head Gasket	(SUB FOR R80241)
9.	T20168	[14]	Washer	(DO NOT USE WITH R85363)
10.	T20183	[14]	Cap Screw	(DIESEL) 1/2" X 4"
10.	R53223	[14]	Cap Screw	(USE WITH BLOCK MARKED R53240) 1/2" X 4-1/4"
10.	R85363	[11]	Cap Screw	(GASOLINE) (SUB FOR T20182 AND R78558)
10.	T20184	[3]	Bolt	(GASOLINE) 1/2" X 3-1/2"
11.	AR102261	[1]	Gasket	(SUB FOR T20111) (ALSO ORDER (6) AR103811 CAP SCREWS WITH WASHERS)
12.	RE44202	[1]	Valve Cover	(SUB FOR AT18016, ALSO ORDER RE32140 SCREW WITH WASHER)
13.	R56463	[1]	O-Ring	(SUB FOR R495R, THIS APPLICATION)
