约翰迪尔零件查询310 - BACKHOE, LOADER CRANKSHAFT AND IDLER GEARS [01B08]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 855 次

Pos.	Part No	Qty	Parts name	Comments
1.	R48685	[1]	Dowel Pin	(SUB FOR A120R)
2.	T26324	[2]	Thrust Washer
3.	R109863	[1]	Shaft	(SUB FOR T26323 AND R89824)
4.	RE46896	[1]	Crankshaft	(MARKED R100142) (WITH BEARINGS AND OIL SEALS) (SUB FOR AT18031,MARKED T23516)
5.	34H283	[1]	Spring Pin	3/16" X 1-1/8"
6.	AR91660	[1]	Gear	(MARKED R70182) (SUB FOR AT18009) (MARKED T20029) (55 TEETH)
7.	T20034	[1]	Bushing
8.	T26326	[2]	Thrust Washer
9.	T26327	[1]	Screw
10.	19H2993	[1]	Cap Screw	1/2" X 1-1/2"
11.	T20217	[1]	Washer
12.	R59915	[1]	Pulley	(SUB FOR R47438)
13.	AT21608	[1]	Seal	(SUB AR67942)
13.	AR67942	[1]	Seal
14.	T20046	[1]	Oil Slinger
15.	T20094	[1]	Helical Gear	(24 TEETH)
16.	T28041	[1]	Shaft Key	(SUB FOR 26H72, THIS APPLICATION)
17.	T23604	[1]	Shaft Key
18A.	T26325	[2]	Screw
18B.	19H3183	[1]	Cap Screw	HS, SAE 8, 1/2" X 2-1/8"
19.	T26321	[1]	Bushing
20.	AT24252	[1]	Gear	(45 TEETH) (MARKED T26322)
21.	34H286	[1]	Spring Pin	3/16" X 1-1/2"
22A.	R76126	[2]	Washer	(SUB FOR R42364)
22B.	R100105	[1]	Washer
23.	RE24959	[1]	Seal	(USE IF AVAILABLE) (SUB FOR AT22965 AND AR92893)
23.	RE44574	[1]	Seal	(SUB FOR RE24959)
24.	T26323	[1]	Shaft
24.	R109863	[1]	Shaft	(SUB FOR R89824)
25.	14H865	[1]	Nut	1/2"
