| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | AT29213 | [3] | Piston Ring | STANDARD (SET OF 3 RINGS) (SUB AR55759) |
| 1. | AR55759 | [3] | Piston Ring Kit | (A) (B) (C) STANDARD, (SET OF 3 RINGS) |
| 2. | M67T | [6] | Snap Ring | (SUB R51112) |
| 2. | R51112 | [6] | Snap Ring | |
| 2. | M41029 | [6] | Snap Ring | |
| 3. | T26149 | [3] | Piston Pin | |
| 3. | R125754 | [3] | Piston Pin | (SUB FOR R51731) |
| 4. | RE53265 | [3] | Piston | (A) (C) STANDARD (BOHN CORPORATION) (SUB FOR R51451, T30015 AND AR78310) WHEN RE53265 REPLACES AR78310 ALL PISTONS MUST BE REPLACED. |
| 4. | AR55984 | [3] | Piston | (A) (SUB AR77762) |
| 4. | AR77762 | [3] | Piston | (B) |
| 5. | T23471 | [3] | Bushing | |
| 5. | R55647 | [3] | Bushing | |
| 6. | RE19733 | [3] | Connecting Rod | (SUB FOR AT18005) |
| 6. | RE21076 | [3] | Connecting Rod | (SUB FOR AR55978 AND RE16495) |
| 7. | R74194 | [6] | Screw | (SUB FOR T20009) (USE WITH AR55978 AND AT18005) |
| 7. | R80033 | [6] | Cap Screw | (USE WITH RE16495, RE19733 AND RE21076) |
| 8. | AT21138 | [3] | Bearing | STANDARD, (SET OF (2) T20011) |
| 8. | ........ | [3] | Bearing | ( AT21122 NO LONGER AVAILABLE) 0.05 MM (.002") UNDERSIZE (SET OF (2) T23566) |
| 8. | AT21124 | [3] | Bearing | 0.25 MM (.010") UNDERSIZE (SET OF (2) T23568) |
| 8. | AT21126 | [3] | Bearing | 0.51 MM (.020") UNDERSIZE (SET OF (2) T23570) |
| 8. | AT21128 | [3] | Bearing | 0.76 MM (.030") UNDERSIZE (SET OF (2) T23572) |
| ... | AR71592 | [1] | Piston-Liner Kit | CYLINDER LINER (CONTAINS CYLINDER LINER WITH O-RINGS AND PISTON WITH PISTON RINGS) |
| ... | AR78041 | [1] | Piston-Liner Kit | CYLINDER LINER (CONTAINS CYLINDER LINER WITH O-RINGS AND PISTON WITH PISTON RINGS) |
| ... | AR71593 | [1] | Piston-Liner Kit | CYLINDER LINER (CONTAINS CYLINDER LINER WITH O-RINGS AND PISTON WITH PISTON RINGS) |
| ... | AR71593 | [1] | Piston-Liner Kit | CYLINDER LINER (CONTAINS CYLINDER LINER WITH O-RINGS AND PISTON WITH PISTON RINGS) |
