约翰迪尔零件查询310 - BACKHOE, LOADER RADIATOR AND TRANSMISSION OIL COOLER [01C12]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 422 次

Pos.	Part No	Qty	Parts name	Comments
1.	T11234	[2]	Lock Nut
2.	24H1305	[2]	Washer	13/32" X 13/16" X 0.065"
3.	R61460	[1]	Rod	(SUB FOR T22495)
4.	24H1122	[1]	Washer	3/8" X 7/8" X 0.083"
5.	19H2664	[1]	Cap Screw	5/16" X 3/4"
6.	AT27585	[1]	Cap
7.	T31651	[1]	Pad
8.	14H785	[5]	Nut	5/16"
9.	12H303	[5]	Lock Washer	5/16"
10.	24H1685	[4]	Washer	11/32" X 47/64" X 0.083"
11.	AT165536	[1]	Oil Cooler	(SUB FOR AT33887)
12.	T35773	[1]	Pad
13.	AR21840	[2]	Hose Clamp
14.	R38481	[1]	Hose	(DIESEL) (SUB FOR R38312)
14.	T33370	[1]	Hose	(GASOLINE)
15.	AR21840	[2]	Hose Clamp
16.	T22500	[1]	Hose
17.	AR21839	[2]	Clamp	(SUB FOR H2742B, THIS APPLICATION)
18.	........	[1]	Hose	19 MM X 57 MM (3/4" X 2-1/4") CLUTCH HOUSING OIL LINE (MAKE FROM T61939, 3 M (10 FT.) ROLL) (SUB FOR T35690)
19.	T33324	[1]	Barrier
20.	T22381	[2]	Washer
21.	R62372	[2]	Spring	(SUB FOR R34352)
22.	19H2458	[2]	Cap Screw	3/8" X 3"
23.	AT13740	[1]	Drain Valve
24.	AT32527	[1]	Radiator
25.	T36499	[1]	Barrier
...	T11847	[1]	Sealant	(NO LONGER AVAILABLE)
...	T19566	[1]	Coolant
