Pos.	Part No	Qty	Parts name	Comments
1.	AT27622	[1]	Cap
2.	T29539	[1]	Washer
3.	T29540	[1]	Fitting
4.	........	[1]	Nut	( R47733 NO LONGER AVAILABLE)
5.	........	[1]	Screw	( R47732 NO LONGER AVAILABLE)
6.	........	[1]	Screw	( R47734 NO LONGER AVAILABLE)
7.	........	[1]	Nut	( R46675 NO LONGER AVAILABLE)
8.	........	[1]	Spring	( R47731 NO LONGER AVAILABLE)
9.	........	[1]	Valve Seat	( R39886 NO LONGER AVAILABLE)
10.	AR49877	[1]	Injection Nozzle	(ROOSA-MASTER NO. 18742) (SUB AR89564)
10.	AR88239	[1]	Injection Nozzle	(ROOSA-MASTER NO. 22042) (SUB FOR AR56290 ROOSA-MASTER NO. 19762 AND AR73673, ROOSA-MASTER NO. 20631) (SUB AR89564)
10.	SE500822	[1]	Nozzle	(CONTAINS (4) REMANUFACTURED NOZZLES)
10.	SE501099	[AR]	Nozzle	(SINGLE PACK) (REMANUFACTURED FOR AR89564)
11.	T26870	[1]	Clamp
12.	R34764	[1]	Washer	(K) (USE WITH AR56290) (SUB RE32011)
12.	R60746	[1]	Washer	(USE WITH AR73673 AND AR88239)
13.	R48000	[1]	Seal
14.	T24472	[1]	Cap
15.	R34760	[1]	Clamp
16.	R34761	[1]	Spacer	(K) (SUB RE32011)
17.	........	[1]	Cap (Hat)	( T31174 NO LONGER AVAILABLE) (USE FOR SERVICING FUEL INJECTION NOZZLE)
18.	T32252	[1]	Washer
18.	T32252	[1]	Washer
19.	24H1685	[1]	Washer	11/32" X 47/64" X 0.083"
19.	24H1685	[1]	Washer	11/32" X 47/64" X 0.083"
