约翰迪尔零件查询310 - BACKHOE, LOADER FUEL INJECTION SYSTEM [01D12]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 833 次

Pos.	Part No	Qty	Parts name	Comments
1.	R48599	[1]	Nut
2.	R132874	[1]	Washer	(SUB FOR R48600)
3.	26H10	[1]	Shaft Key	5/32" X 5/8"
4.	AR49904	[1]	Fuel Injection Pump	(ROOSA-MASTER NO. JDB331AL2406 OR JDB331MD2406)
5.	R35352	[1]	Fitting
6.	21H1317	[2]	Screw	0.190" X 5/8", (USE WITH T23460 AND T23461)
6.	AR76704	[2]	Screw
7.	12H246	[2]	Lock Washer	0.190", (USE WITH T23460 AND T23461)
8.	AT27615	[1]	Fuel Line
9.	AT18099	[1]	Fuel Line	NO. 2
10.	AT18065	[1]	Fuel Line	NO. 1
11.	........	[2]	Hose	(MAKE FROM R68281 1 524 MM (5 FT.) HOSE) (SUB FOR AT32064)
12.	AT27622	[3]	Cap
13.	........	[2]	Hose	(MAKE FROM R68281, 1 524 MM (5 FT.) HOSE) (SUB FOR AT32064)
14.	T29969	[1]	Clamp	(SUB FOR R47281)
15.	R34761	[3]	Spacer	(K) (SUB RE32011)
16.	R34760	[3]	Clamp
17.	R48000	[3]	Seal
18.	R34764	[3]	Washer	(K) (USE WITH AR56290 AND AR89564) (SUB RE32011)
18.	R60746	[3]	Washer	(USE WITH AR73673 AND AR88239)
19.	AR49877	[3]	Injection Nozzle	(SUB AR89564)
19.	AR89564	[3]	Injection Nozzle	(SUB FOR AR56290, AR73673 AND AR88239)
19.	SE500822	[1]	Nozzle	(CONTAINS (4) REMANUFACTURED NOZZLES)
19.	SE501099	[AR]	Nozzle	(SINGLE PACK) (REMANUFACTURED FOR AR89564)
20.	AT18111	[1]	Fuel Line
21.	T23461	[1]	Half Clamp	(SUB R59298, R61145, (2) R59297 AND (2) AR76704)
21.	R59297	[1]	Half Clamp
21.	R61145	[1]	Strap
22.	T23460	[1]	Half Clamp	(SUB R59298, R61145, (2) R59297 AND (2) AR76704)
22.	R59297	[1]	Half Clamp
22.	R59298	[1]	Strap
23.	T20055	[6]	Washer
24.	R26726	[3]	Hollow Screw
25.	14H812	[2]	Nut	3/8"
26.	12H304	[2]	Lock Washer	3/8"
27.	24M7096	[2]	Washer	0.413" X 0.709" X 0.063"
28.	T20052	[2]	Stud
29.	R84663	[1]	Gear	(SUB FOR T20165) (48 TEETH)
30.	24H1685	[3]	Washer	11/32" X 47/64" X 0.083"
30.	24H1685	[3]	Washer	11/32" X 47/64" X 0.083"
31.	T32252	[3]	Washer
31.	T32252	[3]	Washer
32.	TY22462	[2]	Clamp	(SUB FOR AR48236)
