约翰迪尔零件查询310 - BACKHOE, LOADER REAR AXLE HOUSING AND SHAFT [01F08]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 563 次

Pos.	Part No	Qty	Parts name	Comments
1.	T35794	[1]	Shaft	(SUB T38554 AND T38555)
1.	T38554	[1]	Spindle
2.	AT20703	[1]	Seal
3.	L35542	[1]	Guide	(SUB FOR T21429)
4.	JD8946	[1]	Bearing Cone
5.	JD8206	[2]	Bearing Cup
6.	JD7759	[1]	Lubrication Fitting	1/8" STRAIGHT
7.	R27216	[1]	Drain Plug
8.	R26287	[1]	O-Ring
9.	19H1805	[12]	Cap Screw	1/2" X 2-1/4", (WITHOUT PARKING BRAKE AND REAR EXHAUST)
9.	19H1805	[10]	Cap Screw	1/2" X 2-1/4", (WITH PARKING BRAKE)
10.	R21612	[1]	Bleed Valve
11.	AT34775	[1]	Housing	(MARKED T35790 AND GEAR MARKED T21410) (ALSO ORDER (3) T21428 AND (3) R36666)
11.	AT169364	[1]	Housing	(MARKED T105800 AND GEAR MARKED R57200 OR T125844) (SUB FOR AT40757 MARKED T41733 AND GEAR MARKED R57200, AT101717 MARKED T105800 AND GEAR MARKED R57200, AND SUB FOR AT106669 MARKED T105800 AND GEAR MARKED R57200 OR T125844)
11.	T151158	[1]	Ring Gear	(NOT ILLUSTRATED) (MARKED R57200) (SUB FOR T125844)
12.	R26198	[3]	Dowel Pin
13.	R98915	[1]	Gasket	(SUB FOR T21419)
14.	AT124396	[1]	Seal	(SUB FOR AT16887)
15.	JD8151	[1]	Bearing Cone	(SUB FOR JD8992, THIS APPLICATION)
16.	T21428	[3]	Dowel Pin
17.	R47862	[1]	Cap
