约翰迪尔零件查询310 - BACKHOE, LOADER POWER STEERING VALVE HOUSING, WHEEL AND SHAFT (SERIAL NO. -163706) [01F15]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 598 次

Pos.	Part No	Qty	Parts name	Comments
1.	T25329	[1]	Washer
2.	JD9832	[1]	Thrust Bearing
3.	T21716	[1]	Washer
4.	T22824	[1]	Round Retainer
5.	R35226	[1]	Snap Ring	(A)
6.	T34249	[1]	Shaft
7.	L34451	[6]	O-Ring	(A)
8.	RE10800	[1]	Housing	(MARKED R77312) (SUB FOR AT23175, MARKED T25295)
9.	19H3065	[4]	Cap Screw	3/8" X 2"
10.	12H304	[4]	Lock Washer	3/8"
11.	R98910	[1]	Gasket	(A) (SUB FOR T25337)
12.	R26448	[2]	O-Ring	(A)
13A.	AT38033	[1]	Elbow Fitting	(SUB FOR AR26722, THIS APPLICATION)
13A.	AT37206	[1]	Elbow Fitting	(SUB AT54132 AND AT35121)
13B.	AT54132	[1]	Check Valve
14.	T25327	[2]	Back-Up Ring	(A)
15.	U10289	[2]	O-Ring	(A)
16.	T25326	[2]	Back-Up Ring	(A)
17.	F3450R	[1]	O-Ring	(A) (NOT USED WITH R57292 OR R57293)
18A.	T25325	[1]	Piston
18B.	R57292	[1]	Piston	(USE WITH R57293) (SUB R60945) (ALSO ORDER R60946)
18C.	R60945	[1]	Shaft
19.	T34331	[1]	Rod	(SUB R60945) (ALSO ORDER R60946)
20A.	T21655	[1]	Pin	(USE WITH T34331)
20B.	R60946	[1]	Pin	(USE WITH R60945)
21.	R86192	[1]	O-Ring	(A) (SUB FOR U12331)
22.	R78823	[1]	Back-Up Ring	(A) (SUB FOR R35684, THIS APPLICATION)
23.	T25336	[1]	Guide
24.	T25324	[1]	Tie Rod Assembly
25.	T38449	[1]	Retainer	(USED WITH AT37206)
26.	T38448	[1]	Spring	(USED WITH AT37206)
27.	R26552	[1]	Ball	(USED WITH AT37206)
28.	R57293	[1]	Seal	SEALING, (USE WITH R57292)
29.	AT35121	[1]	Elbow Fitting	(USE WITH AT54132)
30.	T25330	[2]	Bushing
31.	T27409	[2]	Washer
32.	AR81610	[2]	Housing	(SUB FOR AT25490)
33.	T25329	[1]	Washer
34.	JD9832	[1]	Thrust Bearing
35.	T21716	[1]	Washer
36.	L29197	[1]	Thrust Washer
37.	T13555	[1]	Spring
38.	T22824	[1]	Round Retainer
39.	R35226	[2]	Snap Ring	(A)
40.	T22823	[1]	Sleeve
41.	T34248	[1]	O-Ring	(A) (SUB FOR B3690R, THIS APPLICATION)
42.	R27320	[1]	Bushing
43.	AT19858	[1]	Adjuster
44.	T22260	[1]	Seal	(A)
45.	T21718	[1]	Nut
46.	AR78405	[1]	Steering Wheel
47.	R71650	[1]	Lock Washer
48.	14H904	[1]	Nut	3/4"
49.	P50631	[1]	O-Ring	(A)
50.	R47998	[1]	Cap
...	AT26188	[1]	Kit	OVERHAUL STEERING VALVE
