约翰迪尔零件查询310 - BACKHOE, LOADER HYDRAULIC OIL LINES (TO PUMP, CLUTCH CONTROL VALVE, FILTER RELIEF VALVE AND RETURN) [01H04]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 525 次

Pos.	Part No	Qty	Parts name	Comments
1.	AT33918	[1]	Oil Line	FILTER RELIEF VALVE TO OIL LINE ADAPTER
2.	AT33917	[1]	Elbow Fitting
3.	R26287	[1]	O-Ring
4A.	AT32335	[1]	Elbow Fitting	(SUB FOR AR26746)
4B.	T21806	[1]	Drain Plug
5.	AT25345	[1]	Line	(HYDRAULIC PUMP TO BRAKE VALVE HOUSING)
5.	AT25345	[1]	Line	(HYDRAULIC PUMP TO CLUTCH HOUSING COVER)
6.	R44302	[8]	Tie Band
7.	AR21839	[4]	Clamp	(SUB FOR T35690, THIS APPLICATION)
8.	........	[1]	Hose	(MAKE FROM T61939 BULK MATERIAL, CUT TO LENGTH) (MAKE FROM T61939) (SUB FOR T35690)
9.	14H785	[1]	Nut	5/16"
10.	T36048	[1]	Bracket
11.	T34888	[1]	Clamp
12.	12H303	[1]	Lock Washer	5/16"
13.	19H1849	[1]	Cap Screw	5/16" X 1-1/4"
14.	T36200	[1]	Clamp
15.	AT34953	[1]	Oil Line	COOLER TO CLUTCH CONTROL VALVE
16.	U13639	[1]	O-Ring
17.	AT33911	[1]	Elbow Fitting
18.	AT34954	[1]	Oil Line	HYDRAULIC PUMP FRONT INLET
19.	........	[1]	Hose	(MAKE FROM U11186 BULK MATERIAL, CUT TO LENGTH) (MAKE FROM U11186) (SUB FOR T35691 AND T37798)
20.	AT33921	[1]	Oil Line	HYDRAULIC PUMP CENTER INLET
21.	AT33923	[1]	Adapter Fitting
22.	19H2676	[1]	Cap Screw	3/8" X 1"
23.	R43696	[1]	Washer	(SUB FOR A4231R)
24.	R1662R	[2]	Washer
25.	14H786	[1]	Nut	1/4"
26.	24H1287	[1]	Washer	9/32" X 5/8" X 0.065"
27.	19H1914	[1]	Cap Screw	1/4" X 1"
