约翰迪尔零件查询310 - BACKHOE, LOADER FRONT AXLE, SPINDLE AND KNUCKLE ASSEMBLY (SERIAL NO. 237998- ) [01H11]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 281 次

Pos.	Part No	Qty	Parts name	Comments
1.	19H1439	[2]	Cap Screw	5/8" X 3"
2.	12H294	[2]	Lock Washer	5/8"
3.	R20135	[2]	Washer
4.	R52383	[4]	Thrust Washer
5.	T71748	[1]	Steering Arm	R.H. (SUB FOR T54444 AND T66936) (SUB T77736) (ALSO ORDER AT76136, AS REQUIRED)
5.	T54445	[1]	Arm	L.H. (SUB T77737) (ALSO ORDER AT76136, AS REQUIRED)
6.	R49838	[4]	Washer
7.	JD7799	[1]	Lubrication Fitting	1/8" 90°
8.	T162396	[2]	Lubrication Fitting	(SUB FOR JD7798) 1/8" STRAIGHT
9.	T23170	[1]	Bushing
10.	R49835	[4]	Bushing
11.	11M7030	[1]	Cotter Pin	5 X 40 MM
12.	14H534	[1]	Nut	3/4", (SUB FOR 14H902)
13.	T25922	[2]	Washer	(USE IF AVAILABLE)
13.	T151797	[2]	Washer	(SUB FOR T25922 OR T134960)
14.	T21669	[1]	Bushing
15.	T25921	[6]	Shim	.38 MM (.015")
16.	T25840	[1]	Cap Screw
17.	34H308	[3]	Spring Pin	1/4" X 1/2"
18.	AT63366	[1]	Front Axle	(LIFETIME SUPPLY) (MARKED T66815) (SUB FOR AT46784) (MARKED T48221)
19.	AT76758	[2]	Knuckle	(SUB FOR AT46785) (ALSO ORDER AT76136, AS REQUIRED)
20.	T48225	[2]	Pin Fastener
21.	11M7087	[2]	Cotter Pin	4 X 40 MM
22.	24H448	[1]	Washer	25/32" X 1-1/8" X 0.090"
