约翰迪尔零件查询310 - BACKHOE, LOADER LOADER BOOM [02D05]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
424 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
........
|
[1] |
Lift Arm
|
|
| 1. |
........
|
[1] |
Lift Arm
|
|
| 2. |
T31905
|
[2] |
Pin
|
|
| 3. |
19H3404
|
[2] |
Cap Screw
|
|
| 4. |
T11234
|
[2] |
Lock Nut
|
|
| 5A. |
T33775
|
[2] |
Pin
|
|
| 5B. |
T40635
|
[2] |
Pin
|
|
| 6. |
19H1912
|
[2] |
Cap Screw
|
|
| 7. |
T162396
|
[2] |
Lubrication Fitting
|
|
| 8. |
JD5645
|
[2] |
Label
|
|
| 9. |
T10671
|
[6] |
Cap Screw
|
|
| 10. |
U41604
|
[8] |
Bushing
|
|
| 11. |
U10616
|
[2] |
Bushing
|
|
| 12. |
U16068
|
[4] |
Snap Ring
|
|
| 13. |
T11234
|
[2] |
Lock Nut
|
|
| 14. |
T162396
|
[4] |
Lubrication Fitting
|
|
