约翰迪尔零件查询310 - BACKHOE, LOADER LOADER CONTROL VALVE LINKAGE [02D09]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
937 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
34H330
|
[4] |
Spring Pin
|
|
| 2. |
U10895
|
[1] |
Pivot
|
|
| 3. |
U11000
|
[1] |
Pin Fastener
|
|
| 4. |
U10897
|
[1] |
Support
|
|
| 5. |
11M7059
|
[3] |
Cotter Pin
|
|
| 6. |
U11001
|
[1] |
Pin
|
|
| 7. |
U43703
|
[1] |
Grip
|
|
| 8. |
T33980
|
[1] |
Lever
|
|
| 9. |
14H821
|
[1] |
Nut
|
|
| 10. |
U11004
|
[2] |
Pin Fastener
|
|
| 11. |
T33982
|
[1] |
Rod
|
|
| 12. |
14H881
|
[2] |
Nut
|
|
| 13. |
T126055
|
[2] |
Turnbuckle
|
|
| 14. |
14H856
|
[2] |
Nut
|
|
| 15. |
U11003
|
[2] |
Pivot
|
|
| 16. |
T33979
|
[2] |
Yoke
|
|
| 17. |
U15097
|
[1] |
Pivot
|
|
| 18. |
12H304
|
[2] |
Lock Washer
|
|
| 19. |
19H2021
|
[2] |
Cap Screw
|
|
| 20. |
T33981
|
[1] |
Rod
|
|
| 21. |
T36272
|
[1] |
Boot
|
|
