约翰迪尔零件查询310 - BACKHOE, LOADER LOADER BOOM CYLINDER (SERIAL NO. -192003) [02D21]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 623 次

Pos.	Part No	Qty	Parts name	Comments
1.	T162396	[2]	Lubrication Fitting	(SUB FOR JD7798) 1/8" STRAIGHT
2.	U42424	[2]	Bushing
3.	........	[1]	Hydraulic Cylinder Barrel	( AT34760 NO LONGER AVAILABLE) (USED WITH RIGHT HAND CYLINDER)
3.	........	[1]	Hydraulic Cylinder Barrel	(USED WITH LEFT HAND CYLINDER) ( AT34762 NO LONGER AVAILABLE)
4.	U13572	[1]	Lock Nut
5.	U17336	[1]	Wear Ring	(A)
6.	U17341	[1]	Piston
7.	T54810	[1]	Packing	(A) (SUB FOR U12973, THIS APPLICATION) (SUB FOR R72825)
8.	A3606R	[1]	O-Ring	(A)
9.	U17344	[1]	Piston
10.	U14128	[1]	Snap Ring
11.	T36998	[1]	Packing	(A) (SUB FOR U44948)
12.	U41823	[1]	Wear Ring	(A)
13.	T34466	[1]	Guide
14.	U12198	[1]	O-Ring	(A)
15.	R81195	[1]	Back-Up Ring	(A) (SUB FOR U13457, THIS APPLICATION)
16.	U13570	[1]	Snap Ring
17.	L1206N	[1]	Seal	(A)
18.	U13566	[1]	Nut
19.	T34259	[2]	Bushing
20.	........	[1]	Rod	( AT33473 - NO LONGER AVAILABLE)
...	........	[1]	Hydraulic Cylinder	( AT34759 NO LONGER AVAILABLE) R.H.
...	AT34761	[1]	Hydraulic Cylinder	L.H.
...	AR105403	[1]	Hydraulic Cylinder Kit	CYLINDER REPAIR, (SUB FOR AT33483 AND AR96505)
