约翰迪尔零件查询310A - BACKHOE, LOADER RIGHT-HAND ENGINE VANDAL SHIELDS (SERIAL NO. 700277- ) [02D16]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
386 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
T13911
|
[AR] |
Plug
|
|
| 2. |
24H1821
|
[8] |
Washer
|
|
| 3. |
T23876
|
[6] |
Screw
|
|
| 4. |
........
|
[2] |
Rivet
|
|
| 5. |
T38006
|
[1] |
Spring
|
|
| 6. |
AT30597
|
[1] |
Door
|
|
| 7. |
19H2721
|
[2] |
Cap Screw
|
|
| 8. |
M453T
|
[1] |
Lock Nut
|
|
| 9. |
03H2119
|
[1] |
Bolt
|
|
| 10. |
AT72269
|
[1] |
Shield
|
|
| 11. |
24H1781
|
[1] |
Washer
|
|
| 12. |
AT72271
|
[1] |
Angle
|
|
| 13. |
12H304
|
[1] |
Lock Washer
|
|
| 14. |
19H2676
|
[1] |
Cap Screw
|
|
| 15. |
12H302
|
[1] |
Lock Washer
|
|
| 16. |
28H1514
|
[1] |
Spacer
|
|
