约翰迪尔零件查询310A - BACKHOE, LOADER HYDRAULIC OIL ACCUMULATOR AND BRACKET (MODEL NOS. 3HA4, 8HA3 AND 8HA4) [02F06]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 437 次

Pos.	Part No	Qty	Parts name	Comments
1.	R27094	[1]	Drain Plug
2.	R26286	[1]	O-Ring
3.	U10136	[2]	Snap Ring
4.	R48957	[1]	End
5.	R78823	[2]	Back-Up Ring	(SUB FOR R35684, THIS APPLICATION)
6.	R86192	[2]	O-Ring	(SUB FOR U12331)
7.	R46986	[1]	Hydraulic Cylinder Barrel
8.	R60038	[1]	Packing	(SUB FOR U12331) (GAS END)
9.	R47085	[1]	Valve
10.	R47087	[1]	Washer
11.	R47086	[1]	Spring
12.	R41877	[1]	Guide
13.	A4728R	[2]	O-Ring
14.	L29015	[2]	Back-Up Ring
15.	R57103	[1]	Piston
16.	R27649	[1]	Back-Up Ring
17.	R47912	[1]	Cap
18.	R28084	[1]	Spring
19.	R47913	[1]	Orifice
20.	14H812	[1]	Nut	3/8"
21.	12H304	[3]	Lock Washer	3/8"
22.	T39887	[1]	Bracket
22.	T73881	[1]	Bracket
23.	R35794	[1]	Clamp
24.	19H3239	[1]	Cap Screw	3/8" X 1-1/4"
25.	24H1367	[2]	Washer	21/32" X 1-1/4" X 1/4"
26.	19H1356	[2]	Cap Screw	5/8" X 1-3/4" (WITH CANOPY)
26.	19H1833	[2]	Cap Screw	5/8" X 1-3/4" (WITHOUT CANOPY)
26.	19H2706	[2]	Cap Screw	5/8" X 2"
27.	19H2284	[2]	Cap Screw	3/8" X 7/8"
28.	24H1139	[1]	Washer	11/16" X 1-1/4" X 0.105"
29.	RE11966	[1]	Accumulator	(SUB RE29331) (ALSO ORDER R80752 ENGLISH LABEL, R80753 SPANISH LABEL, R80754 FRENCH LABEL AND R82337 GERMAN LABEL AS REQUIRED)
30.	24H1302	[1]	Washer	13/32" X 11/16" X 0.035"
