| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | AR26480 | [1] | Seal | |
| 2. | R26632 | [1] | Bushing | |
| 3. | JD9041 | [1] | Bearing Cone | INNER |
| 4. | JD9170 | [1] | Bearing Cup | |
| 5. | R49841 | [1] | Hub | |
| 6. | JD8251 | [1] | Bearing Cup | OUTER |
| 7. | JD8929 | [1] | Bearing Cone | OUTER |
| 8. | 15H638 | [1] | Pipe Plug | 1/8" |
| 9. | 11M7030 | [1] | Cotter Pin | 5 X 40 MM |
| 10. | T75506 | [1] | Washer | (SUB FOR A5146R) (SUB FOR R28575, THIS APPLICATION) |
| 11. | 14H920 | [1] | Nut | 1" |
| 11. | 14M7213 | [1] | Nut | M24 |
| 11. | 14M7519 | [1] | Nut | M24 |
| 12. | R50992 | [1] | Cap |
