| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 19M7949 | [1] | Cap Screw | M12 X 100 |
| 2. | T75383 | [1] | Pin Fastener | |
| 3. | 14M7319 | [1] | Lock Nut | M12 |
| 4. | R46973 | [AR] | Thrust Washer | |
| 5. | N231749 | [10] | Washer | (SUB FOR 24M7236 OR T33089) |
| 6. | T80027 | [2] | Thrust Washer | |
| 7. | 19M8005 | [6] | Cap Screw | M20 X 100 |
| 8. | T140211 | [2] | Bushing | (SUB FOR T69352) |
| 9. | T76753 | [1] | Pivot | |
| 10. | 14M7315 | [2] | Nut | M20 |
| 11. | 19M8157 | [2] | Cap Screw | M20 X 120 |
| 12. | JD7763 | [2] | Lubrication Fitting | 45° |
