现代零件查询25/30GC-7S MIDDLE MAST (TF-MAST)EPC Hyundai
广数供应链运营团队, 16 02月, 2025，浏览：
398 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 2. |
63B1-13010
|
[1] |
MIDDLE MAST WA
|
|
| 2. |
63B1-13020
|
[1] |
MIDDLE MAST WA
|
|
| 2. |
63B1-13030
|
[1] |
MIDDLE MAST WA
|
|
| 2. |
63B1-13040
|
[1] |
MIDDLE MAST WA
|
|
| 2. |
63B1-13050
|
[1] |
MIDDLE MAST WA
|
|
| 2. |
63B1-13060
|
[1] |
MIDDLE MAST WA
|
|
| 2. |
63B1-13070
|
[1] |
MIDDLE MAST WA
|
|
| 2. |
63B1-13080
|
[1] |
MIDDLE MAST WA
|
|
| 2. |
63B1-13090
|
[1] |
MIDDLE MAST WA
|
|
| 2. |
63B1-13100
|
[1] |
MIDDLE MAST WA
|
|
| 4. |
EE19008100
|
[2] |
CHAIN-LIFT
|
|
| 4. |
EE19008700
|
[2] |
CHAIN-LIFT
|
|
| 4. |
EE19009100
|
[2] |
CHAIN-LIFT
|
|
| 4. |
EE19009700
|
[2] |
CHAIN-LIFT
|
|
| 4. |
EE19009900
|
[2] |
CHAIN-LIFT
|
|
| 4. |
EE19010500
|
[2] |
CHAIN-LIFT
|
|
| 4. |
EE19011500
|
[2] |
CHAIN-LIFT
|
|
| 4. |
EE19012500
|
[2] |
CHAIN-LIFT
|
|
| 4. |
EE19012900
|
[2] |
CHAIN-LIFT
|
|
| 4. |
EE19013900
|
[2] |
CHAIN-LIFT
|
|
| 6. |
63HK-18101
|
[4] |
LOAD R/BEARING(117.5)
|
|
| 6. |
63HK-18111
|
[4] |
LOAD R/BEARING(117.2)
|
|
| 6. |
63HK-18121
|
[4] |
LOAD R/BEARING(117.8)
|
|
| 6. |
63HK-18141
|
[4] |
LOAD R/BEARING(118.1)
|
|
| 7. |
6600187900
|
[4] |
SHIM(0.5T)
|
|
| 8. |
6600188000
|
[4] |
SHIM(1.0T)
|
|
| 9. |
63HK-18010
|
[2] |
LINER-BACK UP
|
|
| 10. |
FMC0000160
|
[2] |
SHIM(0.5T)
|
|
| 11. |
37B9AE2030
|
[2] |
SHIM(1.0T)
|
|
| 21. |
63HN-18101
|
[2] |
BRG-CHAIN SHEAVE
|
|
| 22. |
S601-040004
|
[2] |
RING-SNAP
|
|
| 28. |
62HA-18900
|
[4] |
JOINT LINK KIT-CHAIN
|
|
| 29. |
61HA-18800
|
[2] |
BOLT-ANCHOR
|
|
| 30. |
61HA-18810
|
[4] |
BOLT-ANCHOR
|
|
| 31. |
S206-18100B
|
[8] |
NUT-HEX
|
|
| 32. |
S461-320252
|
[4] |
PIN-SPLIT
|
|
| 38. |
S111-120304
|
[2] |
SCREW-SET HEX SOCKET
|
|
| 39. |
S205-12100B
|
[2] |
NUT-HEX
|
|
| 40. |
6DHN-18100
|
[2] |
SHIM
|
|
