| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 19M7815 | [2] | Screw | M12 X 60 |
| 2. | T100381 | [2] | Bar | |
| 3. | AT100359 | [2] | Channel | |
| 4. | 28H1522 | [2] | Spacer | 0.493" X 0.675" X 11/16", (NO LONGER REQUIRED) |
| 5. | 19M7789 | [2] | Screw | M12 X 30 |
| 6. | AT100248 | [1] | Frame | |
| 7. | T100167 | [1] | Grille | |
| 8. | 19M7784 | [6] | Screw | M10 X 20 |
| 9. | 14M7291 | [4] | Flange Nut | M16 |
| 10. | 19M7793 | [4] | Screw | M16 X 40 |
| 10. | 24M7241 | [4] | Washer | 17 X 34 X 4 MM |
| 11. | 14M7275 | [4] | Nut | M12 |
