约翰迪尔零件查询310C - BACKHOE, LOADER THIRD FUNCTION VALVE (MANUAL CONTROL) (SERIAL NO. -738468) [02I09]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 207 次

Pos.	Part No	Qty	Parts name	Comments
1.	AT148686	[1]	Valve	(USE IF AVAILABLE) (SUB FOR AT101872) (ALSO ORDER AT160682)
1.	AT167240	[1]	Valve	(SUB FOR AT148686 AND AT160104)
2.	08H4497	[3]	Cap Screw	3/8" X 9-1/2"
3.	T49819	[2]	O-Ring	(SUB FOR T106368)
4.	T142419	[2]	O-Ring	(SUB FOR T113021)
5.	R44302	[2]	Tie Band
6.	R26906	[2]	O-Ring
7.	38H1172	[1]	Adapter Fitting	(WORK PORT WITHOUT ORIFICE)
7.	T100498	[1]	Adapter Fitting	(WORK PORT WITH ORIFICE) (SUB FOR 38H1172, THIS APPLICATION)
8.	T77613	[4]	O-Ring
9.	AT135725	[2]	Hydraulic Hose - Fabricate	(SUB FOR AT113815)
10.	U40398	[3]	Clamp
11.	28H3381	[2]	Spacer
12.	19H1765	[2]	Cap Screw	3/8" X 1-3/4"
12.	19H2284	[1]	Cap Screw	3/8" X 7/8"
12.	24H1301	[AR]	Washer	13/32" X 9/16" X 0.065"
13.	24H1304	[1]	Washer	13/32" X 23/32" X 0.120"
14.	38H1146	[2]	Fitting Plug
15.	AT114645	[1]	Oil Line	(SUB FOR AT107883)
16.	T77858	[1]	O-Ring
17.	38H1007	[1]	Elbow Fitting
18.	AT114485	[1]	Bracket	(SUB FOR AT113814)
19.	T52805	[2]	Bushing
20.	........	[2]	Cap Screw	(NOT INCLUDED IN KIT)
21.	T19155	[1]	Pin Fastener
22.	24H1287	[2]	Washer	9/32" X 5/8" X 0.065"
23.	AT47913	[1]	Lever
24.	11M7081	[1]	Cotter Pin	2.500 X 20 MM
25.	34H312	[1]	Spring Pin	1/4" X 1"
26.	A3488R	[1]	Grommet
27.	T118642	[1]	Rod	(SUB FOR T113141)
28.	T68099	[1]	Knob
29.	........	[1]	Mounting Parts	(INCLUDES T75654) MANUAL CONTROL ( AT113812 - NO LONGER AVAILABLE)
