| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | AT317121 | [1] | Hydraulic Hose - Fabricate | (ALSO ORDER 62H1042 AND T77613 ) (SUB FOR AT192415, AND AT192416THIS APPLICATION) |
| 1. | 62H1042 | [1] | Adapter Fitting | STC |
| 2. | AT192416 | [1] | Hydraulic Hose - Fabricate | (ALSO ORDER 62H1042 AND T77613) |
| 2. | 62H1042 | [1] | Adapter Fitting | STC |
| 3. | AT186740 | [1] | Hydraulic Hose - Fabricate | (ALSO ORDER 62H1042 AND T77613) |
| 3. | 62H1042 | [1] | Adapter Fitting | STC |
| 4. | T77613 | [3] | O-Ring | |
| 5. | AT192417 | [1] | Tee Fitting | |
| 6. | T186238 | [1] | Adapter Fitting | |
| 7. | R26286 | [1] | O-Ring | |
| 8. | TY22462 | [1] | Clamp | (SUB FOR AR48236) |
