约翰迪尔零件查询310G - BACKHOE, LOADER Hood and Side PanelsEPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 1003 次

Pos.	Part No	Qty	Parts name	Comments
1.	19M7938	[2]	Cap Screw	M10 X 20
2.	24M7239	[3]	Washer	10.700 X 21 X 2.500 MM
3.	19M8600	[2]	Cap Screw	M10 X 50
4.	T165982	[1]	Hood
4.	T209334	[1]	Hood	(SUB FOR T188707)
5.	AT302803	[1]	Support	(SUB FOR AT185683)
6.	19M8637	[3]	Cap Screw	M10 X 40
7.	........	[1]	Latch	ORDER ATTACHING HARDWARE (SUB AT196815 ) (ALSO ORDER (2) 14M7272, (2) 19M7874, (2) 19M7933, (4) 24M7139)
8.	T133487	[1]	Knob
9.	T161373	[2]	Clip
10.	........	[1]	Rod	(T165973 NLA) (SUB AT196815)
11.	19M7077	[2]	Cap Screw	M6 X 20
12.	24M7139	[1]	Washer	6.400 X 18 X 1.600 MM
13.	........	[1]	Latch	(AT185680 NLA) (SUB AT196815)
14.	........	[1]	Latch	(AT191557 NLA) (SUB AT196815)
15.	T165976	[1]	Guide	(RH)
16.	AR91896	[1]	Striker
16.	T259844	[1]	Striker
17.	14M7272	[28]	Nut	M6
18.	19M7874	[2]	Cap Screw	M6 X 30
19.	14H1047	[1]	Nut	7/16"
19.	19M7933	[2]	Cap Screw	M6 X 25
20.	T105740	[1]	Washer
20.	24M7139	[2]	Washer	6.400 X 18 X 1.600 MM
21.	AT189400	[1]	Bracket	STRIKER BOLT BRACKET
21.	T201591	[1]	Bracket	(SUB FOR AT195339)
22.	........	[1]	Plate
23.	T187272	[4]	Screw	(SUB FOR T165985)
24.	........	[1]	Hood	(AT185537 NLA) (AT196355 NLA) (SUB AT329690 ) (ALSO ORDER T188642 AND AT196815)
24.	AT329690	[1]	Hood	(AT311787 NLA)
25.	T184393	[1]	Guide	(LH)
26.	19M9100	[6]	Screw	M6 X 50
27.	19M7373	[4]	Cap Screw	M5 X 20
28.	24M7138	[4]	Washer	5.300 X 15 X 1 MM
29.	T183773	[4]	Nut
30.	21M7246	[8]	Screw	M6 X 16
31.	T165916	[1]	Louver	(LH)
32.	19M8425	[12]	Cap Screw	M6 X 16
33.	AT311786	[1]	Panel	(LH) (SUB FOR AT185539)
34.	19M7933	[10]	Cap Screw	M6 X 25
35.	T165911	[2]	Bushing
36.	........	[1]	Shield	(T183781 NLA) (LH)
37.	T165997	[2]	Insert
38.	T255487	[1]	Bracket	(LH) SUB FOR T184788 GUIDE
39.	T184116	[2]	Label
40.	AT311334	[1]	Gas Operated Cylinder	(SUB FOR AT191760)
41.	T165977	[2]	Extension Spring
42.	AT311785	[1]	Panel	(RH) (SUB FOR AT185538)
43.	T165981	[1]	Compression Spring
44.	R26871	[2]	Snap Ring
45.	24M7047	[3]	Washer	13 X 24 X 2.500 MM
46.	T165978	[1]	Guide
47.	AT189661	[1]	Bar
48.	14M7328	[2]	Lock Nut	M16
49.	24M7241	[2]	Washer	17 X 34 X 4 MM
50.	........	[1]	Shield	(T183780 NLA) (RH)
51.	24H1236	[2]	Washer	13/16" X 2" X 0.149"
52.	T165975	[2]	Bolt
53.	T165915	[1]	Louver	(RH)
54.	T255486	[1]	Bracket	(RH) SUB FOR T184787 GUIDE
55.	19M8637	[2]	Cap Screw	M10 X 40
56.	........	[AR]	Shim
57.	24M7139	[52]	Washer	6.400 X 18 X 1.600 MM
58.	AT196358	[1]	Latch
59.	........	[1]	Bracket
60.	AT196815	[1]	Kit	ALSO OREDR T259844. INCLUDES T188642
61.	19M8637	[2]	Cap Screw	M10 X 40
62.	24M7239	[8]	Washer	10.700 X 21 X 2.500 MM
63.	T188642	[1]	Grommet
